Bently Nevada 200350-09-00-01 High-Precision Industrial Accelerometer Highlighted Features High Sensitivity: 100 mV/g ±20% No Mounting Stud: Flexible installation option Wide Frequency Range: 30 to 600,000 cpm (0.5 to 10,000 Hz) IP68 Protection: Sealed, dust and water-resistant Compact and Lightweight: Height 4.24 cm, Weight 0.051...

Manufacturer: Bently Nevada Product Number: 200350-11-00-CN Product Type: 200350 Accelerometers Made in: U.S.A Mounting Stud Option 11: M6 x 1 Adhesive Stud Mount Model Suffix -00: Sensitivity 100 mV/g ± 20% Model Suffix -CN: Country Specific Approvals Technical Specifications: Hex Size: 11/16 inch (1.8...

Manufacturer: Bently Nevada Product Model: 200350-12-00-01 Product Type: 200350 Accelerometers Made in: U.S.A Certificate Of Origin (COO) available upon request. Mounting Stud Option: 12 = M8 x 1.25 Adhesive Stud Mount Agency Approvals Option: 01 = CSA, ATEX, IECEx Technical Specifications Overview: Hex Size:...

Manufacturer: Bently Nevada Product Number: 200350-12-00-00 Product Type: 200350 Accelerometers Mounting Stud: 12 = M8 x 1.25 Adhesive Stud Mount Mounting Thread: 1/4-28 Female Maximum Mounting Torque: 2 to 5 ft-lb (2.7 to 6.8 N·m) Sensitivity: 100 mV/g ± 20% (10.2 mV/m/s² ± 20%)...

Bently Nevada 200355-00-00-00 Accelerometer | High-Precision Vibration Sensor Brand and Model Information Brand: Bently Nevada Model: 200355-00-00-00 Suffix Details: 00 = ¼-28 Stainless Steel Mount with Brass Tip, 0.5” 00 = 100 mV/g ± 20% Sensitivity 00 = No Agency Approvals Key Technical Specifications...

Bently Nevada 200355-02-00-00 200350 Series Accelerometer Technical Data Range: ±50 g Sensitivity: 100 mV/g ±20% Output Signal: 10.2 mV/m/s² ±20% Frequency Band: 0.5–10,000 Hz (30–600,000 cpm) Temp. Range: –54 °C to +121 °C Supply: 18–28 V DC, 2–20 mA Weight: 0.051 kg Brand: Bently...

Bently Nevada 200355-02-00-CN Accelerometer: High-Performance Vibration Monitoring Solution Key Model Suffix Breakdown -02: ¼-28 to M8 x 1.25 Beryllium Copper mounting stud -00: 100 mV/g sensitivity (±20% tolerance) -CN: Country-specific agency approvals Technical Data Highlights Sensitivity: 100 mV/g (±20%) [10.2 mV/m/s² ±20%] Measurement Range:...

Bently Nevada 200355-10-00-00 200350 Series Accelerometer Key Specifications Model: 200355-10-00-00 Range: ±50 g Sensitivity: 100 mV/g ± 20% Output: 10.2 mV/m/s² ± 20% Freq. Response: 0.5–10 000 Hz (30–600 000 cpm) Temp.: –54 °C to +121 °C Supply: 18–28 V DC, 2–20 mA Weight:...

Manufacturer: Bently Nevada Product Type: 200350 Accelerometers Full Model: 200355-11-00-00 Country of Origin: Made in U.S.A (Certificate Of Origin available upon request) Mounting Stud: 11 = M6x1 Adhesive Stud Mount Mounting Thread: 1/4-28 Female Maximum Mounting Torque: 2 to 5 ft-lb (2.7 to 6.8...

Manufacturer: Bently Nevada Product Type: 200350 Accelerometers Full Model: 200355-12-00-00 Country of Origin: Made in U.S.A (Certificate Of Origin available upon request) Mounting Stud: 12 = M8x1.25 Adhesive Stud Mount Mounting Thread: 1/4-28 Female Maximum Mounting Torque: 2 to 5 ft-lb (2.7 to 6.8...

Manufacturer: Bently Nevada Product Type: 200350 Accelerometers Full Model: 200355-13-00-00 Country of Origin: Made in U.S.A (Certificate Of Origin available upon request) Mounting Stud: 13 = Magnetic Base Kit Mounting Thread: 1/4-28 Female Maximum Mounting Torque: 2 to 5 ft-lb (2.7 to 6.8 N·m)...

23732-01 Bently Nevada - Accelerometer Key Specifications: Sensitivity: 25 mV/g (or 2.55 mV/m/s²) ±5% Peak Acceleration Range: 75 g (equivalent to 735 m/s²) Frequency Response: 10 Hz to 20 kHz (600 cpm to 1.2 million cpm) ±3 dB 30 Hz to 10 kHz (1800...

Technical Specifications Model Number: 330400-01-CN Mounting Thread: ¼-28 UNF integral stud Agency Approval: CN (Specific Country Approval) Sensitivity: 10.2 mV/m/s² (100 mV/g) ±5% Acceleration Range: Up to 490 m/s² (50 g) peak, within 10 Hz to 15 kHz frequency span Amplitude Linearity: ±1% up...

🛠️ Bently Nevada Accelerometer Product Overview Part Number: 330400-02-RU Product Type: Accelerometer Manufacturer: Bently Nevada Ordering Information Model Identifier: 330400 - Accelerometer Mounting Specification: -02 - M8 X 1 Integral Stud Approval Designation: -RU (Regulatory Certification Tags Included) Key Specifications Weight: 0.099 kg (0.218...

🔍 Bently Nevada Accelerometer Product Overview Manufacturer: Bently Nevada Product Number: 330425-02-CN Type: Accelerometer Acceleration Transducers Model: 330425 Mounting Thread: M8 X 1 Integral Stud (02) Agency Approval: Country-Specific (CN) Key Specifications Sensitivity: 2.5 mV/m/s² (25 mV/g) ±5% Amplitude Linearity: ±1% to 735 m/s²...

Manufacturer: Bently Nevada Product Type: High Temperature Acceleration System Full Model: 330450-20 Country of Origin: Made in U.S.A (Certificate Of Origin available upon request) Cable Length: 20 = 2 metres Sensitivity: 10.2 mV/m/s² (100 mV/g) ±5% Acceleration Range: 785 m/s² (80 g) peak, 15...

Bently Nevada Accelerometer 200155-16-05 Electrical Characteristics Sensitivity @ 80 Hz: 10.2 mV/(m/s²) ± 12 % Measurement Range: ± 196 m/s² (± 20 g) Output Impedance: < 150 Ω Noise Floor: 0.8 µg/√Hz @ 10 Hz Bias Drift: < 0.4 mV/°C Insulation Resistance: > 10⁹...

200152-25-00 Model Suffix Breakdown Base Model: 200151 – Interface Cable, Connector on Accelerometer End Only Cable Length: -25 = 25 meters Coupling Nut: -00 = Standard Coupling Nut (Figure 10 style) Electrical & Mechanical Specs Conductor Configuration: 4-wire, 22 AWG Cable Diameter: 6.2 mm...

AP3500T2-Z1 Product Overview: Manufacturer: Bently Nevada Model: Case Mounted Accelerometer Weight : 142 grams Condition: New & Original in Factory Packing Factory Warranty: 12 months Core Dynamic Specifications: Sensitivity ± 5 % @ 25 °C: 500 mV/g Acceleration Range: 10 g peak Amplitude Nonlinearity: 1 % Frequency Response ± 10 %: 0.4 – 1 000 Hz Frequency Response ± 3 dB:...

AS3100S2-Z0 Core Specifications Dynamic Sensitivity: ± 5% at 25°C, 100 mV/g Acceleration Range: 80 g peak Frequency Response: ± 10%: 1.0–5 000 Hz ± 3 dB: 0.7–10 000 Hz Resonant Frequency: 22 kHz Transverse Sensitivity: Max ± 5% of axial Temperature Response: –55°C: –8% +120°C: +10% Voltage Source: 18–30 V dc Current Drive: 2–10 mA (regulated) Broadband Noise: 700 μg (2.5 Hz–25 kHz) Spectral Noise:...
