Brand: GE Fanuc Series: Field Control Model Number: IC670MDL742 Product Type: Negative Logic Output Module Logic Type: Negative Logic (Current Sinking) Number of Outputs: 16 Channels, Single Group User Input Voltage: 4.75–5.25 VDC / 10.5–28.5 VDC Output Voltage Range: 4.5–28.25 VDC Maximum Output Current...

IC670MDL644 Field Control Module Key Specifications Rated Voltage: 24 Volts DC Input Range: 0 – 30 Volts DC User Current: 8 mA @ 24 VDC Inputs: 16 discrete points, grouped Input Impedance: 3 kΩ typical Isolation (Input‑to‑Logic): 250 VAC continuous / 1500 VAC (1 min) Power Draw: 80 mA from backplane LED Indicators: 1 per point; PWR LED...

IC670MDL643 Field Control Module Key Specifications Rated Voltage: 5 / 12 Volts DC Input Range: 0 – 15 Volts DC Inputs: 16 discrete points, grouped User Current: 5 mA @ 5 VDC; 16 mA @ 15 VDC Input Impedance: 1 kΩ typical On‑State Voltage: +3.6 to +15 V / –3.6 to –15 V Off‑State Voltage: 0 to +1.6 V / 0 to –1.6 V Isolation (Group‑to‑Group): 150 VAC Power Draw: 80 mA from...

IC670MDL642 Field Control Module Key Specifications Rated Voltage: 125 Volts DC Input Range: 0 – 150 Volts DC Isolation Voltage: 250 VAC continuous / 1500 VAC (1 min) Inputs: 16 points, grouped (positive/negative logic) User Current: 2.5 mA per point @ 125 VDC On‑State Voltage: +79 to +150 V / –79 to –150 V Off‑State Voltage: 0 to +30 V / 0 to –30 V Response Time: On:...

In Stock Now – GE Fanuc IC670MDD441 Field Control Mixed Discrete Module Key Specifications: Input Channels: 10 discrete DC inputs Output Channels: 6 discrete DC outputs Voltage Range (On-State): 15–30 VDC Voltage Range (Off-State): 0–5 VDC Protection: Includes Short Circuit Protection and Electronic Overcurrent...

Product Name: GE Fanuc IC670CHS103 Field Control I/O Base, Connector Style, Hot Insertion Key Features: Installation Style: Connector style, supports hot insertion Compatible Modules: IC670 / IC670CH / IC670CHS series Rated Voltage: 115 Volts AC or 125 Volts DC Voltage Range: 90–135 Volts AC...

GE Fanuc IC670ALG621 Analog RTD Input Field Control Module Model Full Name and Variants GE Fanuc IC670ALG621 - 4-Channel RTD Input Module Compatible with Genius Bus Interface Unit (BIU) Supports 3-wire and 4-wire RTD sensor connections Key Technical Specifications Input Channels: 4 independent RTD...

Key Functional Features: Model: IC670ALG330 Channels: 8 Analog Current Source Outputs Signal Range: 0.0 – 20.48 mA Resolution: 16-bit DAC, 0.3125 µA per count Update Time: 1.5 ms/channel, typical Load Capacitance: 2000 pF max Load Inductance: 0.5 H max Open Wire Threshold: 1.0 mA...
