330505-02-02-07 Key Specifications Sensitivity: 20 mV/mm/s (508 mV/in/s) ±10% Frequency Response: 0.5 – 1000 Hz (30 – 60 000 cpm) ±3 dB 1 – 200 Hz (60 – 12 000 cpm) ±0.9 dB Velocity Range: 102 mm/s (4 in/s) peak Output Bias Voltage: –12 ± 1 VDC Maximum Cable Length: 305 m (1000 ft) with no signal loss Shock Survivability: 981 m/s² (100 g) peak Operating Temp: –40 °C to...

Key Specifications Model: 330505-01-02-01 (330505 core, “-01” mounting angle, “-02” thread, “-01” adapter option) Sensitivity: 20 mV/mm/s (508 mV/in/s) ±10% Frequency Response: 0.5–1000 Hz ±3 dB; 1–200 Hz ±0.9 dB Velocity Range: 102 mm/s (4 in/s) peakAmplitude Linearity: ±3% up to 102 mm/s peak...

Introducing the Bently Nevada 330505-03-02-03 Low Frequency Velocity Sensor Model Breakdown 330505 — Base series identifier -03 — 180° ± 10° mounting angle -02 — 3/8-24 UNF-2B internal thread -03 — 1/4-28 UNF adapter option Core Specifications Sensitivity: 20 mV/mm/s ±10% (508 mV/in/s) Frequency...

Product Overview The Bently Nevada 330505-03-02-07 Low Frequency Velocity Sensor provides precise and reliable vibration monitoring for industrial rotating equipment. Designed to withstand harsh environments, it ensures optimal machine protection and performance monitoring. Detailed Specifications Sensitivity: 20 mV/mm/s (508 mV/in/s) ±10% Frequency Response: 0.5 – 1000 Hz (30 – 60 000 cpm)...
