Specifications General Information: Parameter Value 🔢 Part Number IC695ALG608 📦 Module Type Analog Input 🏷️ Brand GE Fanuc Input Channels: Parameter Value 📡 Configurable Input Channels 8 single-ended or 4 differential analog inputs 🔌 Supported Signals Current and Voltage input signals Input Signal Ranges:...

PACSystem RX3i Analog Input Module IC695ALG628 Model Details Part Number: IC695ALG628 Platform: PACSystem RX3i HART Version: 5.0 Channels: 8 single‑ended or 4 differential Key Specifications Resolution: 24‑bit ADC with ±0.01 % linearity error Response Time: ≤ 4 ms per channel Input Ranges: ±10 V, 0–10 V, ±5 V, 0–5 V, 1–5 V;...

GE Fanuc IC695ALG704 Analog Output Module Model: IC695ALG704 is compatible with RX3i CPUs (version 3.0 or later) and installs in a single slot on the universal backplane. It supports both voltage and current output modes: Voltage output ranges: ±10 VDC and 0–10 VDC Current...

Technical Specifications Model: IC695ALG708 Series: PACSystem RX3i Output Range: 0 to 20mA, 4 to 20mA, ±10V, 0 to 10V Output Resolution: 15.9 bits for current (0 to 20mA), 14.9 bits for voltage (0 to 10V) Backplane Power: 375mA maximum at 3.3V External Power Supply...

🛠 Technical Specifications Product Information Parameter Specification Brand GE Fanuc (Emerson Automation) Model IC695ALG808 Series PACSystem RX3i Type Isolated Analog Output Module Channels 8 Output Voltage Range ±10V, 0 to +10V Output Current Range 0-20 mA, 4-20 mA Backplane Power Consumption 80 mA @...

IC695 CBL001 Energy Pack Cable Overview Model: IC695 ‒ Suffix: CBL001 is a dedicated Energy Pack Cable designed for GE Fanuc PACSystems RX3i CPUs, ensuring seamless connection between the energy pack and CPU module. Core Specifications Length: 0.91 m (3 ft) Voltage Range: 120–240 VAC / 125 VDC...

GE Fanuc IC695CBL002 Product Highlights: Model: IC695CBL002 Cable Length: 1 meter (36 inches) Connector Type: 7-pin, keyed configuration Voltage Compatibility: 24V DC, 125V DC, 120/240V AC/DC Wiring Type: Straight-through, end-to-end Termination: Integrated termination resistor RoHS Compliance: EU Directive 2011/65/EU Operating Temperature: 0°C to 60°C...

GE Fanuc IC695CBL003 – 0.6m Energy Pack to CPU Connector Cable for RX3i PACSystems Key Technical Details: Model: IC695CBL003 Cable Length: 0.6 meters / 24 inches Voltage Compatibility: 24 VDC, 125 VDC, 120/240 VDC Operating Temperature: 0°C to 60°C (32°F to 140°F) Input/Output Type:...

Technical Specifications Product Information: Parameter Value 📦 Part Number IC695CHS007 🏷️ Brand GE Fanuc (Emerson Automation) 🔧 Series PACSystem RX3i 🏭 Manufacturer Emerson Automation (formerly GE Intelligent Platforms) 🛠️ Type Universal Backplane Physical Specifications: Parameter Value 📏 Dimensions (H x W x D) 141.5...

IC695CMM002 GE RX3i Serial Communications Module Key Features Selectable Baud Rates: 1200, 2400, 4800, 9600, 19.2K, 38.4K, 57.6K, 115.2K Serial Protocols: RS-232, RS-485/422 Connectors: RJ45 Default Flow Control: Full duplex Installations per Rack: Up to 6 modules Power Requirements: 0.7 A at 3.3 VDC,...

IC695CMM004 Overview Key Features & Specifications Dimensions: 130 mm × 44 mm × 140 mm (W × H × D) Weight: 0.25 kg MTBF: 200,000 hours Power Consumption: 0.7 A @ 3.3 VDC; 0.15 A @ 5 VDC Operating Range: 0 °C to 60 °C; Humidity 5 %–95 % non‑condensing Isolation Ratings: Port‑to‑port: 500 VDC continuous; 710 VDC for 1 min Port‑to‑backplane/frame ground: 250 VAC continuous; 1500 VAC...

IC695CPE302 Technical Data Model Prefix: IC695  Model Suffix: CPE302 Processor Speed: 1.1 GHz   Program Storage: 2 MB SRAM/Flash Discrete I/O Capacity: 16 384 bits   Analog I/O Capacity: 16 384 words Power Requirements: 1 A @ +5 VDC, 1 A @ +3.3 VDC, 0.5 A @ +24 VDC Communications: RS‑232 serial, Ethernet port, USB 2.0 Protocol Support: Modbus RTU Slave, SNP Slave, Serial I/O...

IC695CPE310 Technical Specifications Model Prefix: IC695   Model Suffix: CPE310 Processor Speed: 1.1 GHz   User Logic Memory: 10 MB Flash/SRAM Discrete I/O Capacity: 32 768 bits   Analog I/O Capacity: 32 768 words Communication Ports: 1 × Ethernet (10/100 Mbps), 1 × RS‑232, 1 × RS‑485, 1 × USB 2.0 Master Supported Protocols: SNP, Serial I/O, Modbus RTU Slave/Master Power Requirements: 1 A @ +5 VDC, 1 A...

GE Fanuc / Emerson IC695CPK330 – High-Performance RX3i CPU with Energy Pack Technical Specifications Brand: GE Fanuc / Emerson Automation Series: PACSystem RX3i Part Number: IC695CPK330 Processor: 1 GHz CPU (Clock speed: 1.6 GHz internal bus) RAM: 64 MB Non-volatile Memory: 64 MB Energy...

GE Fanuc / Emerson IC695CPU310 PACSystem RX3i Processor Processor Core Specifications Microprocessor Intel Celeron M Clock Speed 300 MHz RAM Memory 10 MB Non-Volatile Memory 10 MB Scan Rate 0.195 ms per 1000 instructions Power Requirement 1.25A at 3.3V DC, 1A at 5V DC...

GE Fanuc IC695CRH017 Harness Assembly – RX3i PACSystems 120/240V AC Output Interface Key Technical Highlights Part Number: IC695CRH017 Voltage Type: AC Rated Voltage: 120/240 Volts AC Line Frequency: 47 – 63 Hertz Max Operating Temperature: 60°C Output Protection: Fused, 3.15A replaceable fuses Output Quantity:...

Model Breakdown: The complete model IC695EDS001 is structured as follows: IC695: Identifies the RX3i platform series. EDS: Denotes Ethernet DNP3 Slave module. 001: Specific variant of the EDS series module. Highlighted Features and Capabilities: Supports 12,072 data points and 20,000 events for reliable, time-critical...

IC695FTB001 Key Features & Core Data Power Input: 19.2 to 28.8 Volts DC, 0.45 Amps at 24 V Output Current (5 V): 0.5 Amps max Digital Outputs: 8 outputs at 24 Volts General Inputs: 16 inputs at 24 Volts Differential I/O: 4 channels at...

Product Highlights Model: IC695HSC308 Counters: 8 configurable types (A, B, C, D, E, Z, and User-defined) Counting Range: -2,147,483,648 to +2,147,483,647 Maximum Count Rate: 1.5 MHz Inputs: 16 high-speed digital inputs Outputs: 14 digital sourcing outputs Advanced Electrical Performance Input Voltage Ranges: 4.7–5.5 VDC...

IC695LRE001 - Serial Bus Transmitter Module Specifications: Maximum Cable Length: 15 meters (50 feet) for Expansion Backplanes 213 meters (700 feet) for Remote Backplanes Current Required: 132 mA at 5 V DC Effective Data Rate: 500k Bytes per second (if the expansion bus includes...
