K-D M12W-3P-2m-PVC Leuze Cable - 3-Pin M12 Sensor

Leuze K-D M12A-3P-2M-PVC Sensor Connection Cable

The Leuze K-D M12A-3P-2M-PVC is a robust industrial cable. It connects sensors and devices with M12 ports. Its 3-pin design and PVC jacket are perfect for factory floors.

• Quick and secure connection for automation devices.
• Durable PVC material resists oil and abrasion.
• Right length for flexibility in cabinet wiring.
• Reliable signal transmission in tough conditions.

Technical Specifications

Brand & Model: Leuze K-D M12A-3P-2M-PVC
Connector Type: M12, Axial, 3-Pin Male
Cable Length: 2 meters
Cable Jacket: PVC (Polyvinyl Chloride)
Conductor Cross-Section: 0.34 mm²
Voltage Rating: Up to 250V AC/DC (3/4-pin standard)
Current Rating: 4 Amps per contact
Insulation Grade: Category I (IEC 60664-1)
Locking Mechanism: Screw fitting, self-locking
Installation Torque: 0.6 Nm recommended
Sheath Diameter: 4.7 to 5.7 mm
Min. Bending Radius: ≥10 x cable diameter
Temp. Range (Flex): -5°C to +70°C
Temp. Range (Fixed): -30°C to +70°C
Color: Black

Frequently Asked Questions (FAQ)

What devices use this type of M12 cable?

It is commonly used to connect sensors, switches, and small actuators in industrial automation.

Can I use this cable outdoors?

The PVC jacket offers good protection, but it is primarily designed for indoor or cabinet use. Check for specific IP ratings if outdoor use is needed.

Is the connector pre-assembled?

Yes, the Leuze K-D M12A-3P-2M-PVC comes with the connector molded onto the cable for a reliable, ready-to-use connection.

How do I ensure a proper seal when connecting it?

Hand-tighten the screw lock until snug, then use a torque wrench to apply the recommended 0.6 Nm for a secure, vibration-proof fit.

What does the 'Axial' type mean for the connector?

It means the cable exits straight out from the back of the connector. This is good for panels where space behind the port is limited.
