133442-01 Bently Nevada I/O Module

Bently Nevada 3500 Series I/O Modules with Internal Terminations

The Bently Nevada 3500 Series I/O Modules provide signal interface between monitoring systems and field devices. Available in non-barrier and internal barrier versions for different application requirements.

Non-Barrier I/O Module Specifications

• Product Type: I/O Module with Internal Terminations (Non-Barrier)
• Dimensions (H x W x D): 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in)
• Weight: 0.20 kg (0.44 lbs)
• Termination Type: Internal screw terminals
• Application: General purpose monitoring without intrinsic safety barriers

Internal Barrier I/O Module Specifications

• Product Type: I/O Module with Internal Terminations (Internal Barrier)
• Dimensions (H x W x D): 241.3 mm x 24.4 mm x 163.1 mm (9.50 in x 0.96 in x 6.42 in)
• Weight: 0.46 kg (1.01 lbs)
• Termination Type: Internal screw terminals with integral safety barriers
• Application: Hazardous area monitoring with intrinsic safety protection

Key Features

• Internal terminations eliminate external junction boxes
• Standard 3500 series form factor
• Plug-in design for 3500 racks
• Screw terminals for field wiring
• Barrier version provides intrinsic safety for hazardous locations
• Non-barrier version for general purpose applications

Package Contents

• 1x Bently Nevada 3500 Series I/O Module (as specified)
• Anti-static protective packaging
• Ships via FedEx, UPS, or DHL

FAQ

• What are the dimensions of non-barrier module?
  241.3 mm x 24.4 mm x 99.1 mm (9.50 x 0.96 x 3.90 inches).
• What are the dimensions of barrier module?
  241.3 mm x 24.4 mm x 163.1 mm (9.50 x 0.96 x 6.42 inches).
• What is the weight difference?
  Non-barrier 0.20 kg, barrier 0.46 kg.
• What termination type is used?
  Internal screw terminals on both versions.
• When to use barrier version?
  For hazardous area applications requiring intrinsic safety barriers.
