21504-00-24-05-02 Bently Nevada Probe Proximity Vibration

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (25 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Bently Nevada 21504-00-24-05-02 Proximity Vibration Probe

Factory Sealed | 12-Month Warranty | ISO 9001 Certified

Critical Specifications

Voltage Range: -17.5VDC to -26VDC (±0.5V tolerance)
Current Load: 12mA max @ 25°C
Detection Range: 0.25mm (10 mils) to 2.0mm (80 mils)
Signal Linearity: ±0.02mm (±0.8 mils) system-calibrated

Precision Engineering

Frequency Bandwidth: DC-10kHz (±5% amplitude variation)
Thermal Drift: -0.39% scale factor/°F at 65°C
Cable Tolerance: +5"/-2" (20" nominal length)
Vibration Resistance: 10g RMS @ 50Hz-2kHz

Mechanical Details

Probe Tip: 8mm diameter non-magnetic stainless steel
Mounting Thread: 3/8-24 UNF-2A
Housing Material: 316L stainless steel casing
Connector Security: IP67-rated MIL-C-39012

Environmental Resilience

Temperature Limits: Probe: -34°C to +177°C (-30°F to +350°F)
Chemical Resistance: Compatible with H2SO4 10%, NH4OH 28%
Shock Survival: 50g peak (11ms half-sine)
Humidity Tolerance: 95% RH non-condensing

Configuration Breakdown

21504-00-24-05-02
00: 0mm Unthreaded Section
24: 2.4" (60.96mm) Case Length
05: 500mm Cable Assembly
02: Coaxial Quick-Disconnect

More Bently Nevada in stock：

330908-12-31-10-02-05 330908-22-31-10-01-05 330908-12-16-10-02-00
330908-12-18-10-02-05 330908-00-16-70-02-EN 330908-00-31-70-02-00
330908-00-16-70-02-00 330908-00-46-70-02-05 990-10-70-03-01
990-10-70-01-CN 990-10-70-02-CN 990-10-70-03-CN
