26530-12-10-00-000-140-21-04-00 Dual Probe Bently Nevada

Bently Nevada 26530-12-10-00-000-140-21-04-00 Dual Probe Transducer System

The Bently Nevada 26530-12-10-00-000-140-21-04-00 is a Dual Probe Transducer System for 3300 Series monitoring. This complete system includes two 8 mm probes with multiple approvals, 1.0 metre probe leads, and 140 mm total probe penetration for industrial machinery protection.

Ordering Code Breakdown

• Part Number: 26530-12-10-00-000-140-21-04-00
• Model: 26530 Dual Probe Transducer System
• Manufacturer: Bently Nevada
• Condition: New & Original in Factory Packing
• Warranty: 12 Months Factory Warranty

Configuration Options

• A: Proximity Probe Option - 12 = 3300 XL 8 mm Probe, Multiple Approvals
• B: Probe Lead Length Option - 10 = 1.0 metre
• C: Adapter Thread Option - 00 = Adapter not required
• D: Adapter Length Option - 000 = No adapter (0.0 inches)
• E: Probe Penetration Option - 140 = 140 mm (14.0 inches x 10)
• F: Extension Cable Length Option - 21 = 2.1 metres
• G: Extension Cable Type Option - 04 = Standard cable with ClickLoc connector
• H: Agency Approval Option - 00 = None specified

Probe Specifications

• Probe Type: 3300 XL 8 mm
• Quantity: Dual probe system (two probes)
• Probe Diameter: 8 mm
• Probe Lead Length: 1.0 metre each
• Probe Penetration: 140 mm total
• Extension Cable Length: 2.1 metres
• Extension Cable Type: Standard with ClickLoc connector
• Agency Approvals: Multiple approvals (per probe option 12)
• Temperature Range: -35°C to +120°C (-31°F to +248°F)
• Pressure Rating: 2000 psi (138 bar) maximum

Electrical Specifications

• Supply Voltage: -24 Vdc nominal
• Gap Range: 0.25 mm to 2.3 mm (10 mils to 90 mils)
• Scale Factor: 7.87 mV/μm (200 mV/mil) typical
• Frequency Response: 0 to 10 kHz
• Linearity: ±1% over full temperature range
• Output Impedance: 50 Ω

Agency Approvals (Probe Option 12)

• CSA: Class I, Division 2, Groups A, B, C, D
• ATEX: II 3 G Ex nA IIC T5 Gc
• IECEx: Ex nA IIC T5 Gc

System Components

• 2x 3300 XL 8 mm proximity probes with multiple approvals
• 2x 1.0 metre probe leads (integral to probes)
• 2x 2.1 metre extension cables with ClickLoc connectors
• No adapter required (adapter option 00)
• 140 mm total probe penetration

Key Features

• Complete dual probe system for redundant measurements
• 3300 XL 8 mm probes with multiple agency approvals
• 1.0 metre integral probe leads
• 2.1 metre extension cables with ClickLoc connectors
• 140 mm probe penetration length
• No adapter required for installation
• Factory-sealed original packaging
• 12-month manufacturer warranty

Package Contents

• 2x Bently Nevada 3300 XL 8 mm Probes with 1.0m leads (multiple approvals)
• 2x Extension cables, 2.1 metres, ClickLoc connectors
• Factory-sealed original packaging
• Ships via FedEx, UPS, or DHL

FAQ

• What is the full part number?
  26530-12-10-00-000-140-21-04-00 Dual Probe Transducer System.
• What probes are included?
  Two 3300 XL 8 mm probes with multiple approvals, 1.0m leads each.
• What is the probe penetration?
  140 mm total penetration length.
• What extension cables are included?
  2.1 metre cables with standard ClickLoc connectors.
• Is an adapter required?
  No, adapter option is 00 = not required.
• What approvals do the probes have?
  Multiple approvals including CSA, ATEX, and IECEx.
