3300 XL Probe 330103-02-12-05-02-CN Bently Nevada

The 330103-02-12-05-02-CN proximity probe belongs to the Bently Nevada 3300 XL vibration monitoring series. This probe measures shaft displacement and vibration in turbines, compressors, and rotating machinery. The compact design provides stable signal output and reliable monitoring performance in demanding industrial environments.

Key Product Overview

• Brand: Bently Nevada
• Model: 330103-02-12-05-02-CN
• Series: 3300 XL 8 mm Proximity Probe
• Designed for shaft vibration and displacement monitoring.
• Compatible with Bently Nevada 3300 XL Proximitor sensors.
• M10 × 1 threaded probe ensures secure installation.
• Country-specific approval option supports regional compliance requirements.

Technical Specifications

• Brand: Bently Nevada
• Model: 330103-02-12-05-02-CN
• Unthreaded probe length: 20 mm.
• Probe case length: 120 mm.
• Total cable length: 0.5 meter.
• Connector type: miniature coaxial ClickLoc connector.
• Probe tip material: Polyphenylene sulfide (PPS).
• Probe case material: AISI 303 or 304 stainless steel.
• Nominal DC resistance: 7.45 Ω ±0.50.

Measurement Performance

• Linear measurement range: 2 mm (80 mils).
• Effective measurement span: 0.25 mm to 2.3 mm.
• Typical output voltage: −1 to −17 Vdc.
• Recommended radial vibration gap: −9 Vdc.

Environmental Limits

• Standard operating temperature: −52°C to +177°C.
• Extended probe tip temperature up to +218°C.
• Cable and connector withstand temperatures up to +260°C.
• Humidity variation remains below 3% ASF during IEC testing.

Installation Guidelines

• Install using the M10 × 1 threaded probe case.
• Maximum thread engagement: 15 mm.
• Adjust probe gap to approximately −9 Vdc.
• Use shielded triad cable for stable signal transmission.

Packaging Information

• 1 × Bently Nevada 330103-02-12-05-02-CN proximity probe
• Industrial protective packaging
• International shipping via FedEx, UPS, or DHL

FAQ

• Which monitoring systems support this probe?
• The probe operates with Bently Nevada 3300 XL Proximitor sensors and vibration monitoring systems.
• What advantage does the ClickLoc connector provide?
• The ClickLoc connector allows fast installation and ensures secure cable connection.
• How can engineers improve measurement stability?
• Correct probe gap adjustment and shielded wiring help maintain stable vibration signals.
