330101-00-67-20-02-CN Bently Nevada 3300 XL 8mm Probe

Bently Nevada 330101-00-67-20-02-CN 3300 XL 8 mm Probe – High-Robustness Proximity Sensor

• Brand & Model: Bently Nevada 330101-00-67-20-02-CN – part of the 3300 XL 8 mm Probe family.
• Nominal DC Resistance (RPROBE): 7.88 ± 0.50 Ω from center conductor to outer conductor for 2.0m length.
• Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical – ensures stable signal transmission.
• Field Wiring: Use 0.2 to 1.5 mm² (16 to 24 AWG) 3-conductor shielded triad cable. Maximum length between Proximitor Sensor and monitor is 305 meters (1,000 feet).
• Linear Range: 2 mm (80 mils) – begins at approximately 0.25 mm (10 mils) from target. Output range is 0.25 to 2.3 mm (10 to 90 mils) corresponding to –1 to –17 Vdc.
• Recommended Gap Setting for Radial Vibration: -9 Vdc [approximately 1.27 mm (50 mils)].
• Incremental Scale Factor (ISF): Standard 5 or 1 meter system provides 7.87 V/mm (200 mV/mil) ±5% including interchangeability error over 0°C to +45°C.
• Deviation from Best Fit Straight Line (DSL): Standard 5 or 1 meter system shows less than ±0.025 mm (±1 mil) at 0°C to +45°C.
• Probe Tip Material: Polyphenylene sulfide (PPS) – provides chemical resistance and durability.
• Probe Case Material: AISI 303 or 304 stainless steel (SST) for strength and corrosion resistance.
• Weight: 323 g/m (11.4 oz) – lightweight for easy handling.
• Probe Temperature Range (Operating & Storage): Standard probe works from -52°C to +177°C (-62°F to +350°F). Extended temperature range probe tip reaches -52°C to +218°C (-62°F to +425°F); cable and connector handle -51°C to +260°C (-60°F to +500°F).
• Probe Pressure Seal: Uses a Viton® O-ring to seal differential pressure between tip and case. Not pressure tested before shipment.
• Probe Relative Humidity: Less than 3% change in Average Scale Factor (ASF) when tested at 93% humidity per IEC 68-2-3 for up to 56 days.
• Thread Engagement Limits: Probe case thread is 3/8-24 with maximum engagement length of 0.563 inches.
• Probe Case Torque (Standard forward mounted probes): Maximum rated torque is 33.9 N•m (300 in•lbf). Recommended torque is 11.2 N•m (100 in•lbf). For first three threads, maximum rated torque is 22.6 N•m (200 in•lbf) with recommended 7.5 N•m (66 in•lbf).

Frequently Asked Questions (FAQ)

• Do you have this 3300 XL 8 mm Probe in stock?
  Yes, we keep this model in stock for immediate orders.
• How long does delivery take and which carriers do you use?
  We ship within 5 business days after order confirmation. We use DHL, FedEx, and UPS for fast and tracked delivery.
• Can I return this probe if it does not fit my application?
  Yes, we support returns within 30 days from delivery, provided the product is unused and in original condition.
• What is the linear range of the 330101-00-67-20-02-CN probe?
  It offers a 2 mm (80 mils) linear range from 0.25 mm to 2.3 mm (10 to 90 mils) from the target.
• What is the maximum temperature for the standard probe?
  The standard probe operates from -52°C to +177°C (-62°F to +350°F). Exceeding this may damage the sensor.
• Does this probe include FluidLoc oil leakage prevention?
  This model does not include FluidLoc. You can order optional FluidLoc cable separately.
• What is the recommended gap setting for radial vibration measurement?
  Set the gap to -9 Vdc, which equals approximately 1.27 mm (50 mils) from the target.
