330103-04-13-10-02-00 3300 XL Probe Bently Nevada

The 330103-04-13-10-02-00 proximity probe is part of the Bently Nevada 3300 XL vibration monitoring series. It measures shaft vibration and displacement in rotating equipment such as turbines, compressors, and pumps. The probe delivers stable signal output and reliable monitoring performance for industrial machine protection systems.

Key Product Overview

• Brand: Bently Nevada
• Model: 330103-04-13-10-02-00
• Series: 3300 XL 8 mm Proximity Probe
• Designed for shaft vibration and displacement monitoring.
• Compatible with Bently Nevada 3300 XL Proximitor sensors.
• Miniature coaxial ClickLoc connector with standard cable.
• Stainless steel probe housing ensures durability.

Technical Specifications

• Brand: Bently Nevada
• Model: 330103-04-13-10-02-00
• Unthreaded probe length: 40 mm.
• Probe case length: 130 mm.
• Total cable length: 1.0 meter.
• Connector type: miniature coaxial ClickLoc connector.
• Probe tip material: Polyphenylene sulfide (PPS).
• Probe case material: AISI 303 or 304 stainless steel.
• Nominal DC resistance: 7.59 Ω ±0.50.

Measurement Performance

• Linear measurement range: 2 mm (80 mils).
• Measurement span: 0.25 mm to 2.3 mm.
• Typical output voltage: −1 to −17 Vdc.
• Recommended radial vibration gap: −9 Vdc.

Environmental Limits

• Operating temperature: −52°C to +177°C.
• Probe tip temperature up to +218°C.
• Cable and connector withstand temperatures up to +260°C.
• Humidity variation below 3% ASF during IEC testing.

Installation Guidelines

• Install using the M10 × 1 threaded probe case.
• Maximum thread engagement: 15 mm.
• Adjust probe gap to approximately −9 Vdc.
• Use shielded triad cable to maintain stable signal transmission.

Packaging Information

• 1 × Bently Nevada 330103-04-13-10-02-00 proximity probe
• Industrial protective packaging
• International shipping via FedEx, UPS, or DHL

FAQ

• What monitoring systems support this probe?
• The probe operates with Bently Nevada 3300 XL Proximitor sensors and vibration monitoring systems.
• What equipment commonly uses this probe?
• It is widely used in turbines, compressors, pumps, and other rotating machinery.
• How can measurement accuracy be maintained?
• Correct probe gap adjustment and shielded wiring help ensure stable vibration monitoring signals.
