330103-06-15-10-12-05 3300 XL 8mm Proximity Probe

The 330103-06-15-10-12-05 proximity probe belongs to the Bently Nevada 3300 XL vibration monitoring series. This sensor measures shaft displacement and vibration in turbines, compressors, and other rotating equipment. The design delivers stable signal output and reliable monitoring performance in demanding industrial environments.

Key Product Overview

• Brand: Bently Nevada
• Model: 330103-06-15-10-12-05
• Series: 3300 XL 8 mm Proximity Probe
• Designed for shaft vibration and displacement monitoring.
• Compatible with Bently Nevada 3300 XL Proximitor sensors.
• FluidLoc cable structure improves reliability in oil-exposed environments.
• CSA, ATEX, and IECEx approvals support hazardous industrial applications.

Technical Specifications

• Brand: Bently Nevada
• Model: 330103-06-15-10-12-05
• Unthreaded probe length: 60 mm.
• Probe case length: 150 mm.
• Total cable length: 1.0 meter.
• Connector type: miniature coaxial ClickLoc with FluidLoc cable.
• Probe tip material: Polyphenylene sulfide (PPS).
• Probe case material: AISI 303 or 304 stainless steel.
• Nominal DC resistance: 7.59 Ω ±0.50.

Measurement Performance

• Linear measurement range: 2 mm (80 mils).
• Effective range: 0.25 mm to 2.3 mm.
• Typical output voltage: −1 to −17 Vdc.
• Recommended radial vibration gap: −9 Vdc.

Environmental Limits

• Standard operating temperature: −52°C to +177°C.
• Extended probe tip temperature up to +218°C.
• Cable and connector tolerate up to +260°C.
• Humidity change remains below 3% ASF at 93% RH testing.

Installation Guidelines

• Install using the M10 × 1 threaded probe case.
• Keep maximum thread engagement within 15 mm.
• Adjust probe gap to approximately −9 Vdc.
• Use shielded triad cable for stable signal transmission.

Packaging Information

• 1 × Bently Nevada 330103-06-15-10-12-05 proximity probe
• Protective industrial packaging
• International delivery via FedEx, UPS, or DHL

FAQ

• Which monitoring systems support this probe?
• The probe operates with Bently Nevada 3300 XL Proximitor sensors and vibration monitoring systems.
• Why choose a FluidLoc cable probe?
• The FluidLoc design prevents oil migration and improves long-term reliability.
• How can installation improve measurement accuracy?
• Correct probe gap, stable mounting, and shielded wiring ensure stable vibration signals.
