330103-06-20-10-02-00 8mm Proximity Probe Bently Nevada

The 330103-06-20-10-02-00 proximity probe is part of the Bently Nevada 3300 XL vibration monitoring series. It measures shaft vibration and displacement in rotating machinery such as turbines, compressors, and motors. The probe provides stable measurement performance and reliable signal output for industrial condition monitoring systems.

Key Product Overview

• Brand: Bently Nevada
• Model: 330103-06-20-10-02-00
• Series: 3300 XL 8 mm Proximity Probe
• Designed for shaft vibration and displacement monitoring.
• Compatible with Bently Nevada 3300 XL Proximitor sensors.
• Miniature coaxial ClickLoc connector with standard cable.
• Robust stainless steel housing for industrial environments.

Technical Specifications

• Brand: Bently Nevada
• Model: 330103-06-20-10-02-00
• Unthreaded probe length: 60 mm.
• Probe case length: 200 mm.
• Total cable length: 1.0 meter.
• Connector type: miniature coaxial ClickLoc connector.
• Probe tip material: Polyphenylene sulfide (PPS).
• Probe case material: AISI 303 or 304 stainless steel.
• Nominal DC resistance: 7.59 Ω ±0.50.

Measurement Performance

• Linear measurement range: 2 mm (80 mils).
• Measurement span: 0.25 mm to 2.3 mm.
• Typical output voltage: −1 to −17 Vdc.
• Recommended radial vibration gap: −9 Vdc.

Environmental Limits

• Operating temperature: −52°C to +177°C.
• Probe tip temperature up to +218°C.
• Cable and connector withstand temperatures up to +260°C.
• Humidity testing shows less than 3% scale factor variation.

Installation Guidelines

• Install using the M10 × 1 threaded probe case.
• Maximum thread engagement: 15 mm.
• Set probe gap to approximately −9 Vdc.
• Use shielded triad cable to maintain signal stability.

Packaging Information

• 1 × Bently Nevada 330103-06-20-10-02-00 proximity probe
• Industrial protective packaging
• International shipping via FedEx, UPS, or DHL

FAQ

• What monitoring systems support this probe?
• The probe works with Bently Nevada 3300 XL Proximitor sensors and vibration monitoring systems.
• What is the typical application of this probe?
• It monitors shaft vibration and displacement in turbines, compressors, pumps, and motors.
• How can signal stability be improved?
• Proper probe gap adjustment and shielded wiring help ensure accurate vibration measurement.
