330172-00-08-10-02-05 Bently Nevada Armored 5mm Probe Sensor

Bently Nevada 330172-00-08-10-02-05 Armored 5mm Probe

Key Electrical & System Specifications

• Power requirement: Needs -17.5 Vdc to -26 Vdc at 12 mA maximum consumption. Operating above -23.5 Vdc reduces linear range.
• Supply sensitivity: Less than 2 mV output change per volt of input change. This ensures stable readings.
• Output resistance: 50 Ω for standard load compatibility. Works with a 10 kΩ load during factory tests.
• Probe DC resistance: For 1.0 meter length, center to outer conductor resistance is 7.59 ± 0.50 Ω.
• Cable type: 75 Ω triaxial with fluoroethylene propylene (FEP) insulation. Standard cable length is 1.0 metre (3.3 feet).
• Connector option: Miniature coaxial ClickLoc connector (code 02) on standard cable.
• Agency approval option: Code 05 = multiple approvals. Suitable for worldwide hazardous locations.

Frequently Asked Questions (FAQ)

• Q: Is this 330172-00-08-10-02-05 a new original Bently Nevada probe?
  A: Yes, absolutely. We supply only brand new, factory-sealed units. No used or third-party copies.
• Q: What does the armor protect against?
  A: The armor protects the probe cable from cuts, abrasion, and mechanical wear. Ideal for harsh industrial environments.
• Q: What does unthreaded length option 00 mean?
  A: Unthreaded length 0.0 inch means the thread starts immediately at the probe tip. This gives full thread engagement control.
• Q: What are the multiple approvals (code 05)?
  A: Code 05 means multiple agency approvals for hazardous locations. It includes certifications like ATEX, IECEx, and CSA.
• Q: Can I use this probe at temperatures below -30°F?
  A: The probe works from -35°C to +177°C. However, exposing it below –34°C (-30°F) may cause premature pressure seal failure. Follow the temperature schedule carefully.
• Q: What is the recommended torque for mounting?
  A: Recommended torque is 5.1 N·m (45 in·lb). Maximum allowed torque is 7.3 N·m (65 in·lb). Exceeding this damages the probe case.
• Q: How long does shipping take?
  A: We dispatch within 5 days. Express shipping via FedEx, UPS, or DHL usually takes 3-7 business days depending on destination.
• Q: Do you offer returns?
  A: Yes, we support 30-day returns for unused items. Contact us first for return authorization.
• Q: What power supply works best with this proximity probe?
  A: Use a -24 Vdc supply at 12 mA maximum. Operation more positive than -23.5 Vdc reduces linear range, so maintain -17.5 to -26 Vdc.
• Q: What is the thread size and maximum engagement?
  A: Thread is 1/4-28 UNF. Maximum length of thread engagement is 0.375 inch (9.5 mm). Always respect this limit.
