330173-04-08-10-02-00 Bently Nevada 5mm Probe

Bently Nevada 330173-04-08-10-10-02-00 5mm Proximity Probe Overview

Key Technical Specifications

• Manufacturer & Model: Bently Nevada 330173-04-08-10-02-00 (3300 5mm Probe)
• Thread Type: M8 x 1, without armor
• Unthreaded Length: 40 mm (Option 04)
• Overall Case Length: 80 mm (Option 08)
• Total Cable Length: 1.0 metre (3.3 feet, Option 10)
• Connector Type: Miniature coaxial ClickLoc connector with standard cable
• Agency Approval: Not required (Option 00)
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 304 stainless steel (SST)
• Weight: 0.323 Kg
• Probe DC Resistance (1.0m): 7.59 ± 0.50 Ω (center to outer conductor)
• Output Resistance: 50 Ω
• Temperature Range (Probe): -35°C to +177°C (-31°F to +351°F)
• Low Temperature Limit Warning: Exposing the probe below -34°C (-30°F) may damage the pressure seal.
• 60 Hz Magnetic Field Immunity (5m system at 50 mil gap): Probe output voltage change = 0.0014 mV pp/gauss
• Recommended Probe Case Torque: 5.1 N·m (45 in·lb)
• Maximum Probe Case Torque: 7.3 N·m (65 in·lb)
• Minimum Cable Bend Radius: 25.4 mm (1.0 inch)
• Tensile Strength: 222 N (50 lbf) for probe case to lead, and lead to extension cable connectors.
• Thread Engagement Limit (M8x1): Maximum 12 mm

Installation & Torque Guidelines

• Use the recommended probe case torque of 5.1 N·m (45 in·lb).
• Do not exceed the maximum torque of 7.3 N·m (65 in·lb) to avoid damage.
• Apply a connector-to-connector torque up to 0.565 N·m (0.42 ft·lbf) for reliable connections.
• Respect the thread engagement limit of 12 mm for the M8x1 case thread.
• Maintain a minimum cable bend radius of 25.4 mm (1.0 inch) to protect the cable.
• Use the probe with a AISI 4140 steel target for specified performance.
• Gap the probe at 1.27 mm (50 mils) for optimal linear range under standard conditions.

Frequently Asked Questions (FAQ)

• Is this Bently Nevada 330173-04-08-10-02-00 probe brand new?
  Yes, we guarantee a brand new and original Bently Nevada 330173-04-08-10-02-00 probe.
• Do you have this model in stock?
  Yes, we keep the 330173-04-08-10-02-00 in stock for immediate shipment.
• What is the return policy?
  We accept returns within 30 days from the delivery date.
• What happens if I expose the probe below -34°C?
  Temperatures below -34°C (-30°F) may cause premature failure of the pressure seal.
• Can I use this probe with an extension cable?
  Yes, it works with Bently Nevada extension cables; ensure the connector torque does not exceed 0.565 N·m.
• Does the probe require a specific target material?
  Yes, the standard specifications assume an AISI 4140 steel target for accurate readings.
