Bently Nevada 330703-000-100-10-02-05 Proximity Probe

Core Technical Specifications

  • Model & Part Number: 330703-000-100-10-02-05 from the 3300 XL 11 mm probe family.
  • Thread & Armor: M14 x 1.5 thread without armor.
  • Length Configuration: Unthreaded length 00 mm, overall case length 100.0 mm, total length 1.0 metre (3.3 feet).
  • Connector Type: Miniature coaxial ClickLoc connector with standard cable.
  • Agency Approval: Multiple Approvals (option 05).
  • DC Resistance (1.0 m): Center to outer conductor resistance 5.9 ± 0.5 ohms.
  • 60 Hz Magnetic Field Immunity (up to 300 Gauss): Output (mil pp/gauss) at 0.5 mm gap = 0.001; at 2.5 mm = 0.009; at 4.6 mm = 0.027.
  • Probe Tip Material: Polyphenylene sulfide (PPS) for robust sensing.
  • Probe Case Material: AISI 304 stainless steel (SST) resists corrosion.
  • Probe Cable: 75 Ω triaxial FEP insulated cable, available in 1, 5, or 9 metres.
  • Maximum Case Torque: 63.3 N•m (560 in•lb); recommended torque 21.1 N•m (187 in•lb).
  • Maximum Thread Engagement: 21 mm for the M14x1.5 thread.
  • Temperature Range (Operating/Storage): -52°C to +177°C (-62°F to +351°F).
  • Temperature Schedule: EPL Ga/Gc classifications from T1 to T5; EPL Dc from T280°C to T90°C.

Environmental & Performance Features

  • The 3300 XL series probe operates reliably in extreme temperatures from -52°C to +177°C.
  • It withstands magnetic fields up to 300 Gauss with minimal output voltage deviation.
  • Polyphenylene sulfide tip and stainless steel case ensure long-term durability.
  • The triaxial cable with FEP insulation provides excellent signal integrity.
  • This model (330703-000-100-10-02-05) offers multiple agency approvals for global compliance.

    Frequently Asked Questions (FAQ)

    • Is this 330703-000-100-10-02-05 a genuine new product?
      Yes, we supply only brand new, original products in factory packaging.
    • What is the availability of this probe?
      We currently have stock available for this model.
    • How long does shipping take?
      We ship within 5 working days via FedEx, UPS, or DHL.
    • Can I return the probe if it does not meet my needs?
      Yes, we accept returns within 30 days of delivery.
    • What is the maximum torque for the M14x1.5 thread?
      The recommended torque is 21.1 N•m; the maximum is 63.3 N•m.
    • Does the probe operate in high magnetic fields?
      Yes, it performs well up to 300 Gauss with minimal output deviation.
    • What is the temperature limit for this sensor?
      The operating range is -52°C to +177°C, but avoid exposure below -34°C.
