330705-02-18-50-00-00 Bently Nevada 3300 XL 11mm Probe

Bently Nevada 3300 XL 11 mm Reverse Mount Probe

• Manufacturer: Bently Nevada (Made in U.S.A).
• Model Number: 330705-02-18-50-00-00.
• Probe Type: 3300 XL 11 mm Reverse Mount Probe.
• Total Length: 5.0 meters (16.4 feet).
• Connector: Miniature ClickLoc™ coaxial connector.
• Agency Approval: Not required (Option 00).

Key Technical Specifications

• Probe Tip Material: Polyphenylene sulfide (PPS) for durability.
• Probe Case Material: AISI 304 stainless steel (SST).
• Cable Specification: 75 Ω triaxial, FEP insulated cable.
• DC Resistance (RPROBE): 7.2 ± 0.8 ohms (center to outer conductor).
• Operating Temperature: -51°C to +177°C (-60°F to +351°F).
• Storage Temperature: -52°C to +177°C (-62°F to +351°F).

Environmental & Mechanical Ratings

• Pressure Seal: Viton® O-ring seals differential pressure.
• Probe Case Torque (Max): 22.6 N•m (200 in•lb).
• Probe Case Torque (Recommended): 7.5 N•m (66 in•lb).
• Connector Torque (Max): 0.565 N•m (5 in•lb).
• Minimum Bend Radius: 25.4 mm (1.0 in) with or without armor.
• Weight: 0.07 Kg (lightweight design).

Hazardous Area Approvals

• Intrinsic Safety (ia): Class I, Zone 0 (AEx/Ex ia IIC T4/T5 Ga). Also Class I, II, III, Groups A-G.
• Nonincendive (nA/ec): Class I, Zone 2 (AEx/Ex nA IIC T4/T5 Gc & ec IIC T4/T5 Gc).
• Temperature Class: T5 @ Ta = -55°C to +40°C; T4 @ Ta = -55°C to +80°C.
• Installation: Use with intrinsic safety barriers (drawing 141092) or galvanic isolators.

Installation & Handling Guidelines

• Use finger tight for connector-to-connector torque initially.
• Do not exceed the maximum rated case torque of 22.6 N•m.
• Avoid exposing the probe below -34°C to prevent pressure seal failure.
• Maintain a minimum bend radius of 25.4 mm for cable routing.
• Store the probe within the specified temperature range.

Package Contents

• 1 x Bently Nevada 3300 XL Reverse Mount Probe (330705-02-18-50-00-00).
• Pre-attached 5.0 meter triaxial FEP cable with Miniature ClickLoc™ connector.
• Product documentation and installation notes.

Shipping & Logistics

• We ship via FedEx, UPS, or DHL for fast delivery.
• Orders dispatch within 5 business days from our warehouse.
• All items are new original factory stock.
• We offer a 30-day return policy for eligible products.

Frequently Asked Questions (FAQ)

• Q: Is this probe a new original unit?
  A: Yes, we supply only new original Bently Nevada probes.
• Q: What is the total length of this model?
  A: The 330705-02-18-50-00-00 has a 5.0 metre (16.4 ft) total length.
• Q: What connector does it use?
  A: It features the Miniature ClickLoc™ coaxial connector (Option 00).
• Q: What hazardous area approvals does it have?
  A: It has Intrinsic Safety (ia) and Nonincendive (nA/ec) approvals for Zone 0, Zone 2, and Div 2.
• Q: Do you have stock available?
  A: Yes, we have this probe in stock for immediate shipment.
• Q: How quickly will you ship?
  A: We dispatch all orders within 5 days after order confirmation.
• Q: What shipping carriers do you use?
  A: We use FedEx, UPS, and DHL for reliable global delivery.
• Q: Can I return this product?
  A: Yes, we accept returns within 30 days of delivery.
• Q: What is the pressure sealing capability?
  A: The Viton® O-ring provides differential pressure sealing; contact us for custom testing.
