330709-000-030-50-02-05 Bently Nevada 3300 XL 11 mm Probe

Bently Nevada 3300 XL 11 mm Proximity Probe – Model 330709-000-030-50-02-05

• Manufacturer: Bently Nevada (Made in U.S.A).
• Model Number: 330709-000-030-50-02-05.
• Probe Type: 3300 XL 11 mm Proximity Probe without armor.
• Thread Specification: M16 x 1.5 thread.
• Unthreaded Length: 0 mm (option 000).
• Overall Case Length: 30 mm (option 030).
• Total Probe Length: 5.0 meters (16.4 feet). This 5 meter probe works only with the 5 meter Proximitor Sensor.
• Connector Type: Miniature coaxial ClickLoc connector with standard cable (option 02).
• Agency Approval: Multiple Approvals (option 05).

Electrical & Environmental Specifications

• Probe DC Resistance (RPROBE): 7.2 ± 0.8 ohms between center and outer conductor (5.0 m length).
• Target Size (Flat Surface): Recommended minimum diameter 30.5 mm (1.2 in).
• Shaft Diameter: Recommended minimum 152 mm (6.0 in).
• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 304 stainless steel (SST).
• Probe Cable: 75 Ω triaxial, FEP insulated; available in 1, 5, or 9 meter total lengths.
• Operating & Storage Temperature: -52°C to +177°C (-62°F to +351°F). Exposing the probe below -34°C (30°F) may damage the pressure seal.
• Temperature Classifications (EPL Ga/Gc): T1 (-55°C to +232°C), T2 (-55°C to +177°C), T3 (-55°C to +120°C), T4 (-55°C to +80°C), T5 (-55°C to +40°C).
• Temperature Classifications (EPL Dc): T280°C (-55 to 232°C), T225°C (-55 to 177°C), T170°C (-55 to 120°C), T130°C (-55 to 80°C), T105°C (-55 to 100°C), T90°C (-55 to 40°C).
• Cross-talk Limitation: Follow recommended target sizes to avoid interference.

Mechanical & Installation Guidelines

• Probe Case Torque (M16x1.5): Recommended 21.1 N•m (187 in•lb); Maximum rated 63.3 N•m (560 in•lb).
• Connector-to-Connector Torque: Finger tight recommended; Maximum 0.565 N•m (5 in•lb).
• Minimum Bend Radius: 25.4 mm (1.0 in) with or without SST armor.
• Maximum Thread Engagement Length: 24 mm for M16x1.5 threads.
• Installation Tip: Use the recommended torque values to prevent damage.
• Probe Case Thread: M16x1.5, ensure proper engagement.

Packaging & Logistics

• Package Contents: One 3300 XL 11 mm Proximity Probe (Model 330709-000-030-50-02-05) with ClickLoc connector.
• Shipping Methods: We use FedEx, UPS, and DHL for fast delivery.
• Stock Status: Brand new original units in stock.
• Dispatch Time: We ship within 5 business days after order confirmation.
• Return Policy: We support 30-day returns for unused items.

Frequently Asked Questions (FAQ)

• Q: Is this probe compatible with extension cables?
  A: This 5.0 meter probe works specifically with the 5 meter Proximitor Sensor. Do not use it with other lengths.
• Q: What is the correct torque for the probe case?
  A: We recommend 21.1 N•m (187 in•lb) for the M16x1.5 thread. Do not exceed 63.3 N•m.
• Q: Can I use this probe in high-temperature areas?
  A: Yes, the probe operates from -52°C to +177°C. Check the temperature classification table for specific EPL requirements.
• Q: What is the minimum target size?
  A: For flat surfaces, we recommend a minimum 30.5 mm diameter. For shafts, use at least 152 mm diameter.
• Q: Is this a genuine Bently Nevada product?
  A: Yes, this is a brand new original 3300 XL probe made in the U.S.A.
• Q: How long does delivery take?
  A: We dispatch within 5 days via FedEx, UPS, or DHL. Transit times depend on your location.
