330709-000-030-90-01-05 Bently Nevada 11mm Probe

Bently Nevada 3300 XL 11 mm Proximity Probe – Model 330709-000-030-90-01-05

Key Technical Specifications

• Manufacturer & Series: Bently Nevada, 3300 XL series.
• Product Number: 330709-000-030-90-01-05 – 11 mm probe, M16 x 1.5 thread, without armor.
• Unthreaded Length: 0 mm (Option 000).
• Overall Case Length: 30 mm (Option 030).
• Total Cable Length: 9.0 meters (29.5 feet) – Option 90.
• Connector Type: Miniature coaxial ClickLoc with connector protector, standard cable (Option 01).
• Agency Approval: Multiple Approvals (Option 05).
• Probe DC Resistance (RPROBE): 8.5 ± 1.1 ohms (center to outer conductor at 9.0m).
• Target Size (Flat Surface): Recommended minimum diameter 30.5 mm (1.2 in).
• Shaft Diameter (Recommended Min): 152 mm (6.0 in).
• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 304 stainless steel.
• Cable Specification: 75 Ω triaxial, FEP insulated, available in 1, 5, or 9 meter lengths.
• Probe Case Torque (M16x1.5): Recommended 21.1 N•m (187 in•lb); Maximum rated 63.3 N•m (560 in•lb).
• Connector-to-connector torque: Finger tight recommended; Max 0.565 N•m (5 in•lb).
• Minimum Bend Radius (with/without armor): 25.4 mm (1.0 in).
• Thread Engagement (Max): 24 mm for M16x1.5.

Temperature & Environmental Ratings

• Operating & Storage Temperature: -52°C to +177°C (-62°F to +351°F).
• Note on Low Temperature: Exposure below -34°C (-30°F) may affect the pressure seal.
• Temperature Schedule (Probe Only – EPL Ga/Gc):
  • T1: -55°C to +232°C
  • T2: -55°C to +177°C
  • T3: -55°C to +120°C
  • T4: -55°C to +80°C
  • T5: -55°C to +40°C
• Temperature Schedule (EPL Dc):
  • T280°C @ Ta: -55°C to +232°C
  • T225°C @ Ta: -55°C to +177°C
  • T170°C @ Ta: -55°C to +120°C
  • T130°C @ Ta: -55°C to +80°C
  • T105°C @ Ta: -55°C to +100°C
  • T90°C @ Ta: -55°C to +40°C

Installation & Handling Guidelines

• Apply recommended torque of 21.1 N•m (187 in•lb) for the M16x1.5 probe case.
• Do not exceed the maximum rated torque of 63.3 N•m (560 in•lb).
• Finger-tighten the connector, and never exceed 0.565 N•m (5 in•lb).
• Maintain a minimum bend radius of 25.4 mm (1.0 in) to protect the cable.
• Thread engagement length must not exceed 24 mm.
• For best performance, use a flat target of at least 30.5 mm diameter.
• Ensure the shaft diameter is at least 152 mm for proper operation.

Package Contents

• 1 x Bently Nevada 330709-000-030-90-01-05 probe assembly (9.0m cable).
• 1 x Miniature coaxial ClickLoc connector with protector.
• Installation quick-guide (basic torque & handling notes).

Shipping & Logistics

• We ship via FedEx, UPS, or DHL – tracking provided.
• Orders dispatch within 5 business days.
• Stock availability: in stock and ready to ship.

Frequently Asked Questions (FAQ)

• Q: Is this a genuine Bently Nevada probe?
  A: Yes, it is a brand new, original 330709-000-030-90-01-05 from Bently Nevada.
• Q: What is the total cable length?
  A: The total length is 9.0 meters (29.5 feet) with standard FEP cable.
• Q: What approvals does this probe carry?
  A: It has Multiple Approvals (Option 05) for various hazardous area classifications.
• Q: What is the recommended torque for installation?
  A: Use 21.1 N•m (187 in•lb) for the M16x1.5 case; do not exceed 63.3 N•m.
• Q: Do you have these in stock?
  A: Yes, we maintain stock and can dispatch within 5 days.
• Q: What is your return policy?
  A: We support returns within 30 days of delivery.
• Q: Which shipping carriers do you use?
  A: FedEx, UPS, and DHL are our standard carriers.
