330709-000-030-90-11-05 Bently Nevada 11mm Proximity Probes

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (15 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7
  • Vendor:

    Bently Nevada

  • Type:

    11mm Probe

  • Tags 11mm probe

About the Product

Bently Nevada 3300 XL 11 mm Proximity Probe – Model 330709-000-030-90-11-05

Key Technical Specifications

  • Manufacturer & Series: Bently Nevada, 3300 XL series.
  • Product Number: 330709-000-030-90-11-05 – 11 mm probe, M16 x 1.5 thread, without armor.
  • Unthreaded Length: 0 mm (Option 000).
  • Overall Case Length: 30 mm (Option 030).
  • Total Cable Length: 9.0 meters (29.5 feet) – Option 90.
  • Connector & Cable Type: Miniature coaxial ClickLoc with protector and FluidLoc cable (Option 11).
  • Agency Approval: Multiple Approvals (Option 05).
  • Probe DC Resistance (RPROBE): 8.5 ± 1.1 ohms (center to outer conductor at 9.0m).
  • Target Size (Flat Surface): Recommended minimum diameter 30.5 mm (1.2 in).
  • Shaft Diameter (Recommended Min): 152 mm (6.0 in).
  • Probe Tip Material: Polyphenylene sulfide (PPS).
  • Probe Case Material: AISI 304 stainless steel.
  • Cable Specification: 75 Ω triaxial, FEP insulated, available in 1, 5, or 9 meter lengths.
  • Probe Case Torque (M16x1.5): Recommended 21.1 N•m (187 in•lb); Maximum rated 63.3 N•m (560 in•lb).
  • Connector-to-connector torque: Finger tight recommended; Max 0.565 N•m (5 in•lb).
  • Minimum Bend Radius (with/without armor): 25.4 mm (1.0 in).
  • Thread Engagement (Max): 24 mm for M16x1.5.

Frequently Asked Questions (FAQ)

  • Q: Is this a genuine Bently Nevada probe?
    A: Yes, it is a brand new, original 330709-000-030-90-11-05 from Bently Nevada.
  • Q: What is the total cable length?
    A: The total length is 9.0 meters (29.5 feet) with FluidLoc cable.
  • Q: What approvals does this probe carry?
    A: It has Multiple Approvals (Option 05) for various hazardous area classifications.
  • Q: What is the recommended torque for installation?
    A: Use 21.1 N•m (187 in•lb) for the M16x1.5 case; do not exceed 63.3 N•m.
  • Q: Do you have these in stock?
    A: Yes, we maintain stock and can dispatch within 5 days.
  • Q: What is your return policy?
    A: We support returns within 30 days of delivery.
  • Q: Which shipping carriers do you use?
    A: FedEx, UPS, and DHL are our standard carriers.
