330730-080-02-05 | Bently Nevada 11 mm Extension Cable

Bently Nevada 330730-080-02-05 is a high-performance 3300 XL 11 mm Extension Cable designed for precision measurement in industrial environments. Engineered with gold-plated ClickLoc connectors and patented CableLoc technology, this extension cable ensures reliable signal transmission with 330 N (75 lb) pull strength and 69.9 pF/m capacitance.

Key Specifications

• Length: 8.0 meters (26.2 feet) with ±0.5Ω core-to-core resistance and ±0.2Ω coaxial resistance
• Temperature Range: Operates from -51°C to +177°C (-60°F to +351°F) with FEP insulation for chemical resistance
• Agency Approvals: Complies with 05 Multiple Approvals for global industrial standards

Advanced Design Features

• Armor Option: Flexible AISI 302 SST armor adds 140 g/m (1.5 oz/ft) weight for crush resistance up to 1,500 N/m²
• FluidLoc Technology: Prevents liquid ingress with 75Ω triaxial construction and IP67-rated connector protectors (optional)
• Signal Integrity: Maintains ≤0.5 dB signal loss across 305 meters (1,000 feet) field wiring

Technical Performance

• Linear Range: 4.0 mm (160 mils) with -17 Vdc output at 4.5 mm gap
• Frequency Response: 0-12 kHz bandwidth (±3 dB) for dynamic machinery monitoring
• Thread Options: Compatible with ½-20, 5⁄8-18, M14x1.5, M16x1.5 probe configurations

Installation Advantages

• Safety Locknut: Pre-drilled holes allow 1.2 mm safety wire installation per ASME B46.1 standards
• Cable Flexibility: Minimum bend radius of 25 mm (1 inch) for tight spaces
• Calibration: Factory-calibrated for AISI 4140 steel, customizable for other materials

Includes silicone tape and Certificate of Origin (COO) upon request. For technical specifications or bulk orders, contact sales@nex-auto.com.
