3500/45-01-00 Position Monitor Module | Bently Nevada

Core Product Overview

• The Bently Nevada 3500/45-01-00 is a Position Monitor module.
• This module provides precise position measurement for rotating machinery.
• It features internal terminations for simplified transducer connection.

Key Technical Specifications

• Manufacturer & Model: Bently Nevada 3500/45-01-00
• I/O Module Type: 01 = Position I/O Module with Internal Terminations
• Agency Approval: 00 = No Special Agency Approvals Required
• Transducer Support: Proximitor, RPT, and DC LVDT inputs
• Operating Temperature: -30°C to +65°C (-22°F to +150°F)
• Humidity Rating: 95% non-condensing operation
• Module Weight: 0.91 Kg total weight

Functional & Environmental Features

• Transducer Compatibility: Accepts Proximitor, RPT, and DC LVDT signals
• Internal Terminations: Built-in resistors eliminate external components
• Wide Temperature Range: Operates from -30°C to +65°C
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• High Humidity: 95% non-condensing environmental tolerance
• Position Monitoring: Measures axial and radial displacement

Physical & Installation Specifications

• Dimensions: 24.13 cm x 2.44 cm x 24.18 cm (H x W x D)
• Rack Space: Requires 1 full-height front slot
• Mounting: Standard 3500 series rack installation
• Connection: Internal terminations for easy wiring
• Origin: Manufactured in the United States of America
• Documentation: Certificate of Origin (COO) available

Ordering & Configuration Details

• Base Model: 3500/45 Position Monitor
• First Option: 01 = Position I/O Module with Internal Terminations
• Second Option: 00 = No Agency Approval Required
• Complete Part Number: 3500/45-01-00
• Transducer Types: Proximitor, RPT, DC LVDT compatible
• Condition: New original equipment from factory

Installation & Configuration

• Install the 3500/45-01-00 module in a 3500 system rack
• Connect position transducers directly to module terminals
• No external termination resistors required due to internal design
• Configure position monitoring parameters using 3500 software
• Set alarm and danger thresholds for machinery protection

Packaging & Delivery

• One Bently Nevada 3500/45-01-00 Position Monitor Module
• Original factory packaging with complete documentation
• Shipping via FedEx, UPS, or DHL express delivery
• Certificate of Origin available for international shipments

Frequently Asked Questions

What position transducers are compatible?

The 3500/45-01-00 works with Proximitor, RPT, and DC LVDT transducers.

What are the main benefits of internal terminations?

They simplify installation by eliminating external termination resistors.

What is the operating temperature range?

It operates reliably from -30°C to +65°C in harsh environments.

How much rack space does it require?

It requires one full-height front slot in the 3500 rack.

Where is this product manufactured?

It is manufactured in the United States of America.
