6ES7214-1HG40-0XB0 CPU 1214C Siemens Compact Controller

Siemens SIMATIC S7-1200 CPU 1214C Advanced Compact PLC

The Siemens 6ES7214-1HG40-0XB0 represents a powerful automation solution in a compact footprint. This enhanced CPU 1214C model delivers expanded I/O capacity and increased memory for complex applications. It combines robust performance with flexible connectivity options for modern industrial environments.

Core Technical Specifications

• Brand: Siemens
• Model: 6ES7214-1HG40-0XB0 (CPU 1214C DC/DC/Relay)
• Power Supply: 20.4 - 28.8 V DC with reverse polarity protection
• Integrated I/O: 14 Digital Inputs (24V DC), 10 Relay Outputs (2A), 2 Analog Inputs (0-10V)
• Program Memory: 150 KB work memory with 4 MB load memory
• Communication: Built-in PROFINET port with 100 Mbit/s speed
• Operating Temperature: -20 °C to 60 °C horizontal mounting

Comprehensive Input and Output Configuration

• The fourteen digital inputs handle 24V DC signals with configurable filtering
• Six inputs support high-speed counting up to 100 kHz for motion control
• Ten relay outputs manage resistive loads up to 2A with 10 ms response time
• Two analog inputs process 0-10V signals with 10-bit resolution accuracy
• Each analog channel completes conversion within 625 µs for rapid response

Advanced Communication Features

• The integrated PROFINET interface supports both controller and device roles
• Multiple protocols including TCP/IP, ISO-on-TCP, and UDP for flexibility
• OPC UA server functionality enables secure data exchange between systems
• Integrated web server allows remote monitoring and configuration access
• Supports expansion with 8 signal modules and 3 communication modules

Environmental Durability and Compliance

• Wide operating temperature range from -20°C to 60°C for harsh conditions
• High immunity to electromagnetic interference and voltage surges
• Withstands vibrations up to 2g and mechanical shocks up to 15g peak
• IP20 protection ensures safety against contact with small objects
• Carries CE, UL, cULus, FM, and marine approvals for global application

Installation and Setup Guidelines

• Mount on standard DIN rails in control cabinets or industrial panels
• Use shielded cables for analog signals, maximum 100 meters length
• Digital inputs support unshielded cables up to 300 meters distance
• Ensure proper spacing for ventilation, especially at higher temperatures
• Follow electrical standards and local safety regulations during installation

Packaging and Shipping Information

• Package Dimensions: 11.60 x 11.40 x 8.30 cm (L x W x H)
• Net Weight: 0.384 kg
• Shipping Weight: Approximately 0.435 kg
• Contents: One Siemens CPU 1214C unit (6ES7214-1HG40-0XB0)
• We ship globally using FedEx, UPS, and DHL express delivery services

Frequently Asked Questions

• What software is required for programming? STEP 7 (TIA Portal) V18 or higher
• How many expansion modules can be added? Up to 8 signal modules and 3 communication modules
• What is the relay contact lifetime? 100,000 operational cycles at rated load conditions
• Does it support data logging functions? Yes, with configurable traces up to 512 KB memory capacity
• What high-speed counting capabilities are available? Six inputs support counting up to 100 kHz frequency

For technical specifications and purchasing information, contact our specialists. Reach us through WhatsApp or send an email for immediate support.
