8200-224 Woodward Servo Position Controller

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (99 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Technical Specifications

Specification Details
Model 8200-224
Manufacturer Woodward
Current Range ±10 mA to ±250 mA
Input Filter 5 ms lag
Input Impedance 400 kΩ
Linearity 0.1% of Full Scale
Power Supply Voltage 24 V DC ±20%
Power Dissipation 20 W (typical heat load)
Operating Temperature Range -40°C to +70°C
Humidity Up to 95% non-condensing
Temperature Sensitivity 300 ppm/°C
Response Time < 1 ms for step changes in input
Output Signal 0-10 V or 4-20 mA (configurable)
Communication Interface RS-232 / RS-485 (optional)
Dimensions 5.0" x 4.5" x 3.0" (127 mm x 114 mm x 76 mm)
Weight 1.5 lbs (0.68 kg)
Mounting Type DIN rail mountable
  • Quick Quotes: Receive pricing and availability fast from our dedicated customer service team.
  • Delivery: Expedited, freight, and international shipping available worldwide.
  • Warranty: NexAuto offers a 12-month warranty on all parts purchased from us, in addition to any manufacturer coverage.
  • Returns: 30-day return policy for defective or mismatched parts, ensuring peace of mind.
  • Payment: Flexible options including major credit cards, PayPal, and bank transfers.
  • Custom Calibration: Provide your specifications, and we’ll handle the rest with precision.
