  • AI801-1
  • AI801-2
1 3

AI801 Analog Input Module ABB

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (20 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

ABB AI801 Analog Input Module Overview

Technical Specifications

Article Number 3BSE020512R1
Type Analog Input
Signal Specification 0...20 mA, 4...20 mA
Number of Channels 8
Signal Type Unipolar Single Ended
Resolution 12 Bit
Input Impedance 230 - 275 Ω (incl. PTC)
Isolation Groupwise isolated from ground
Input Filter Rise Time 180 ms
Update Cycle 1 ms
Max Field Cable Length 600 meters
Max Input Voltage 30 V d.c.
Current Consumption +5V Modulebus: 70 mA, +24V external: 30 mA
Wire Size Solid: 0.05-2.5 mm², Stranded: 0.05-1.5 mm²
Recommended Torque 0.5-0.6 Nm
Stripping Length 6-7.5 mm
Protection Class IP20
Operating Temperature 0 to +55 °C
Storage Temperature -40 to +70 °C
Power Dissipation 1.1 W

Diagnostics

  • Front LEDs indicate run or fault status
  • Supervision for module error, warning, and channel errors

Certifications and Environment

  • CE Marked and complies with EN 61010-1/2-201, UL 61010-1/2-201
  • Hazardous location approved: C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2
  • Marine certifications: ABS, BV, DNV, LR
  • Relative humidity: 5–95%, non-condensing
  • Pollution degree: 2, Corrosion protection: ISA-S71.04 G3

FAQ

  • Is this module brand new? Yes, AI801 is fully new and original from ABB.
  • Do you have stock available? We have AI801 in stock ready for dispatch.
  • How do you ship the module? We usually ship via DHL or other reliable couriers.
  • What is the return policy? You can return AI801 within 30 days if it meets our conditions.
  • What is the maximum cable length supported? AI801 supports up to 600 meters of field cabling.
  • What input voltage is safe? The analog inputs can withstand up to 30 V d.c. without damage.
