Allen-Bradley 2711P-K6M8A 6 inch Industrial HMI Display

Allen-Bradley 2711P-K6M8A PanelView Plus 600 HMI

The Allen-Bradley 2711P-K6M8A delivers reliable performance for industrial automation applications. This HMI terminal offers clear visibility and robust operation in demanding environments.

Display Specifications

• Display Resolution: 320 × 240 pixels
• Active Viewing Area: 112 × 84 mm
• Front Brightness: 440 cd/m² typical
• Display Type: Monochrome grayscale

Power Requirements

• Input Power: 85 - 264 V AC
• Frequency Range: 47 - 63 Hz
• Typical Power Draw: 20 VA
• Maximum Power Draw: 35 VA

Physical Dimensions

• Overall Dimensions: 167 × 266 × 98 mm
• Mounted Depth: 98 mm
• Panel Cutout Size: 123 × 156 mm
• Shock Rating: 15g at 11 ms operating

Installation Guide

• Prepare panel cutout measuring 123 × 156 mm for proper fit
• Ensure adequate clearance for depth requirement of 98 mm
• Connect to AC power source between 85-264 V AC
• Verify frequency compatibility from 47-63 Hz
• Mount securely to withstand industrial shock and vibration

Environmental Specifications

• Designed for industrial operating environments
• High brightness display for factory lighting conditions
• Robust construction for reliable performance
• Suitable for manufacturing and control applications

Packaging & Shipping

• Allen-Bradley 2711P-K6M8A HMI Terminal
• All necessary mounting hardware included
• Manufacturer documentation provided
• Shipping via FedEx, UPS, and DHL available

Frequently Asked Questions

• What is the display resolution? 320 × 240 pixels
• What power supply does it need? 85-264 V AC
• What is the panel cutout size? 123 × 156 mm
• How bright is the display? 440 cd/m² typical
• What is the typical power consumption? 20 VA
