About the Product

Allen-Bradley 1734-IM4

4-Channel Digital AC Input Module

The 1734-IM4 features four sink-style inputs rated 159–264 VAC (nominal 220 VAC @ 60 Hz), with a hardware filter delay of 20 ms and a programmable digital filter from 1 ms to 65.535 ms.

Electrical & Performance

• POINTBus current max: 75 mA
• Input current: 6.2 mA (@159 VAC) to 10.2 mA (@264 VAC)
• Input impedance: 22.3 kΩ
• Power dissipation: 0.80 W max @264 VAC
• Thermal dissipation: 2.73 BTU/h max @264 VAC
• Isolation voltage: 240 VAC field-to-system

Mechanical & Installation

Key switch position: 8. Mounts on 1734-TB/TBS/TOP/TOPS bases; accepts 14–22 AWG copper.

Dimensions: 2.21″ × 0.47″ × 2.97″; Weight:0.031kg. Open-style enclosure.

Indicators & Environment

LEDs for network, module, and inputs 0–3. Operating temp: –20 °C to 55 °C; non-op: –40 °C to 85 °C; humidity: 5–95% non-condensing. Shock: 30 g op, 50 g non-op; vibration: 5 g @ 10-500 Hz.

Warranty

Warranty period: 1 year.
