Bently Nevada 330102-00-25-10-02-CN Probe 8mm Armored

Bently Nevada 330102-00-25-10-02-CN belongs to the trusted 3300 XL 8 mm Proximity Probe series. We engineered this probe for permanent vibration and position monitoring in harsh turbomachinery. It delivers precise, linear displacement measurements with a rugged armor and PPS tip.

Key technical specifications

• Brand: Bently Nevada. Model: 330102-00-25-10-02-CN (3300 XL 8 mm).
• Linear range: 2 mm (80 mils). Span from 0.25 to 2.3 mm (–1 to –17 Vdc).
• Recommended gap: –9 Vdc ≈ 1.27 mm (50 mils) for radial vibration.
• Probe tip material: Polyphenylene sulfide (PPS). Case: AISI 303/304 SST.
• DC resistance (RPROBE): 7.59 ± 0.50 Ω (1.0 m length).
• Temperature range: -52°C to +177°C (-62°F to +350°F).
• Relative humidity: Less than 3% ASF change after 56 days at 93% RH (IEC 68-2-3).
• Thread size: 3/8-24 UNF. Max engagement: 0.563 in. Probe mass: 323 g/m (11.4 oz/ft).
• Connector: Miniature coaxial ClickLoc with standard cable.
• Pressure seal: Viton® O-ring, differential pressure design.
• Agency approvals: Country specific (CN option).
• Overall case length: 2.5 inches. Unthreaded length: 0.0 inches.
• Total probe length: 1.0 meter (3.3 feet).

Installation and wiring guidelines

• Use 3-conductor shielded triad cable, 0.2 to 1.5 mm² (16 to 24 AWG).
• Maximum field wiring length: 305 meters (1,000 feet) to monitor.
• Recommended gap setting: -9 Vdc for radial vibration applications.
• Thread engagement max: 0.563 inch. Do not exceed this limit.
• The 2.5 inch case length suits compact installations with limited space.
• Intrinsically safe: Class I, Zone 0 with zener barriers per drawing 141092.
• Non-incendive: Class I, Zone 2 per drawing 140979.
• For extended temperature, probe tip withstands up to +218°C.

Environmental and mechanical resistance

• Standard operating temperature: -52°C to +177°C (-62°F to +350°F).
• Extended tip rating: up to +218°C. Cable rating: up to +260°C.
• Below -34°C, pressure seal may fail prematurely. Take caution.
• Humidity tested: Less than 3% ASF shift after 56 days at 93% RH.
• Probe case: AISI 303/304 stainless steel for corrosion resistance.
• Probe tip: Polyphenylene sulfide (PPS) offers high durability.

What's in the package

• 1x Bently Nevada 330102-00-25-10-02-CN probe with armor.
• 1x Miniature coaxial ClickLoc connector (pre-attached).
• Factory configuration sheet with mechanical drawing.
• Standard Bently Nevada installation manual.
• Country specific approval documentation (CN).

Shipping options

• FedEx International Priority.
• UPS Worldwide Express.
• DHL Express Easy.
• All orders ship within 24 hours.

Frequently asked questions

What does the CN approval option mean?

The CN option indicates country specific approvals tailored for local regulatory requirements. For 330102-00-25-10-02-CN, this typically includes certifications needed for installation in China or regions with unique compliance standards.

What is the advantage of 2.5 inch case length?

The 2.5 inch case length offers a compact profile for machines with limited mounting depth. It provides enough rigid length for stable installation while minimizing overhang in tight spaces.

Can I use this probe with a 5 meter Proximitor?

No. 5-meter probes require a 5-meter Proximitor sensor. This 1.0 meter probe works with standard Proximitors. Always match total length to sensor type for proper calibration.

What is the maximum thread engagement depth?

Maximum thread engagement is 0.563 inch. With 2.5 inch case length and 0.0 unthreaded section, threads begin immediately. Use care to not exceed the engagement limit when setting the -9 Vdc gap.

Is this probe suitable for hazardous areas?

Yes, with proper installation using zener barriers or galvanic isolators per drawing 141092, it meets Class I, Zone 0 requirements. The CN approval ensures compliance with local hazardous area regulations.
