Bently Nevada 330103-00-16-10-12-05 Vibration Probe

The 330103-00-16-10-12-05 proximity probe is part of the Bently Nevada 3300 XL vibration monitoring series. It is designed to measure shaft vibration and displacement in rotating machinery such as turbines, compressors, and pumps. This probe features a FluidLoc cable and ClickLoc connector to provide secure connections and reliable signal transmission in demanding industrial environments.

Key Product Overview

• Brand: Bently Nevada
• Model: 330103-00-16-10-12-05
• Series: 3300 XL 8 mm Proximity Probe
• Used for shaft vibration and displacement monitoring.
• Compatible with Bently Nevada 3300 XL Proximitor sensors.
• FluidLoc cable design enhances resistance to fluid ingress.
• Miniature coaxial ClickLoc connector ensures stable connections.

Technical Specifications

• Brand: Bently Nevada
• Model: 330103-00-16-10-12-05
• Unthreaded probe length: 0 mm.
• Probe case length: 160 mm.
• Total cable length: 1.0 meter.
• Connector type: miniature coaxial ClickLoc connector.
• Cable type: FluidLoc industrial cable.
• Probe tip material: Polyphenylene sulfide (PPS).
• Probe case material: AISI 303 or 304 stainless steel.
• Nominal DC resistance: 7.59 Ω ±0.50.

Measurement Performance

• Linear measurement range: 2 mm (80 mils).
• Measurement span: 0.25 mm to 2.3 mm.
• Typical output voltage: −1 to −17 Vdc.
• Recommended radial vibration gap: −9 Vdc.

Environmental Limits

• Operating temperature: −52°C to +177°C.
• Probe tip temperature up to +218°C.
• Cable and connector withstand temperatures up to +260°C.
• Humidity variation below 3% ASF during IEC testing.

Installation Guidelines

• Install using the M10 × 1 threaded probe case.
• Maximum thread engagement: 15 mm.
• Adjust probe gap to approximately −9 Vdc.
• Use shielded triad cable for stable signal transmission.

Packaging Information

• 1 × Bently Nevada 330103-00-16-10-12-05 proximity probe
• Industrial protective packaging
• International shipping via FedEx, UPS, or DHL

FAQ

• What is the advantage of a FluidLoc cable?
• The FluidLoc cable helps prevent fluid ingress and improves reliability in harsh industrial environments.
• Which monitoring systems are compatible?
• The probe is designed for use with Bently Nevada 3300 XL Proximitor sensors and vibration monitoring systems.
• What equipment commonly uses this probe?
• It is commonly installed in turbines, compressors, pumps, and other rotating machinery.
