Bently Nevada 330104-01-06-10-01-05 8mm Probe

Bently Nevada 330104-01-06-10-01-05 3300 XL 8 mm Proximity Probe

The Bently Nevada 330104-01-06-10-01-05 is a 3300 XL 8 mm proximity probe from the 3300 Series. This probe features a 10 mm unthreaded length and 60 mm overall case length with 1.0 metre total cable.

Technical Specifications

• Part Number: 330104-01-06-10-01-05
• Model: 3300 XL 8 mm Proximity Probes
• Manufacturer: Bently Nevada
• Condition: New & Original in Factory Packing
• Warranty: 12 Months Factory Warranty

Suffix Code Configuration

• Model: 330104 - 3300 XL 8 mm Proximity Probes
• Unthreaded Length: 01 - 10 mm (0.39 in)
• Overall Case Length: 06 - 60 mm (2.36 in)
• Total Length: 10 - 1.0 metre (3.3 feet)
• Connector & Cable: 01 - Miniature coaxial ClickLoc connector with connector protector, standard cable
• Agency Approval: 05 - CSA, ATEX, IECEx Approvals

Physical Specifications

• Probe Diameter: 8 mm
• Sensing Tip Material: Polyphenylene sulfide (PPS)
• Case Material: 300 series stainless steel
• Cable Type: Standard coaxial, flexible
• Connector Type: Miniature coaxial ClickLoc with protective cap
• Temperature Range: -35°C to +120°C (-31°F to +248°F)
• Pressure Rating: 2000 psi (138 bar) maximum

Electrical Specifications

• Supply Voltage: -24 Vdc nominal
• Gap Range: 0.25 mm to 2.3 mm (10 mils to 90 mils)
• Scale Factor: 7.87 mV/μm (200 mV/mil) typical
• Frequency Response: 0 to 10 kHz
• Linearity: ±1% over full temperature range
• Output Impedance: 50 Ω

Agency Approvals

• CSA: Class I, Division 2, Groups A, B, C, D
• ATEX: II 3 G Ex nA IIC T5 Gc
• IECEx: Ex nA IIC T5 Gc
• Multiple approvals for global hazardous locations

Key Features

• 8 mm diameter for standard mounting applications
• 10 mm unthreaded length for flexible positioning
• 60 mm overall case length
• 1.0 metre (3.3 feet) total cable length
• Miniature coaxial ClickLoc connector with protector
• CSA, ATEX, and IECEx certified
• Factory-sealed original packaging
• 12-month manufacturer warranty

Package Contents

• 1x Bently Nevada 330104-01-06-10-01-05 Proximity Probe
• Connector protector installed
• Factory-sealed original packaging
• Ships via FedEx, UPS, or DHL

FAQ

• What is the full part number?
  330104-01-06-10-01-05 for 3300 XL 8 mm proximity probe.
• What are the length options?
  10 mm unthreaded length, 60 mm overall case, 1.0 metre total cable.
• What connector is included?
  Miniature coaxial ClickLoc connector with protective cap, standard cable.
• What agency approvals does it have?
  CSA, ATEX, and IECEx for hazardous locations.
• What is the temperature range?
  -35°C to +120°C (-31°F to +248°F).
• What is the typical scale factor?
  7.87 mV/μm (200 mV/mil) with ±1% linearity.
