Bently Nevada 330880-28-00-035-00-02 PROXPAC XL Proximity Transducer

Product Overview

Manufacturer: Bently Nevada

Product No.: 330880-28-00-035-00-02

Product Type: PROXPAC XL Proximity Transducer

Made in: U.S.A

The 330880-28-00-035-00-02 proximitor sensor is a key component for reliable vibration monitoring in industrial rotating machinery. This sensor is designed for systems requiring high accuracy and durability in harsh environments.

Key Configuration

• Probe and Approvals Option: 3300 XL 8 mm probe with multiple approvals, ensuring compatibility and safety in a variety of applications.
• Standoff Adapter Option: 0.0 in, no adapter included, for straightforward installation.
• Probe Penetration: 35mm, allowing for precise positioning in monitoring systems.
• Fittings Option: No fittings; includes two plugs and two washers for secure sealing and minimal installation time.
• Mounting Thread Option: 3/4-14 NPT, required if ordering the standoff adapter option.

Technical Specifications

• Brand: Bently Nevada
• Model: 330880-28-00-035-00-02
• Linear Range: 2 mm (0.25 mm to 2.3 mm)
• Frequency Response: 0 to 10 kHz
• Sensitivity: 7.87 V/mm ±5%
• Resolution: High precision with less than ±0.025 mm deviation.
• Recommended Gap: 1.27 mm (50 mils)
• Output Resistance: 50 Ω
• Supply Voltage: -17.5 Vdc to -26 Vdc

Mechanical and Material Details

• IP66-rated housing protects the device from dust and powerful water jets.
• PPS materials provide strong chemical resistance and long-term mechanical durability.
• Stainless steel construction improves corrosion resistance in harsh industrial environments.
• UV-resistant housing ensures stable performance in outdoor and high-exposure conditions.
• ClickLoc connector design allows fast and secure electrical connections.
• Silicone vibration isolation reduces mechanical noise and improves measurement stability.

Environmental Performance

• Operating temperature ranges from -51°C to +177°C for demanding industrial applications.
• Certified impact resistance ensures durability under mechanical shock conditions.
• Wide temperature classification supports hazardous and industrial installation environments.

Installation Guidelines

• Set the probe gap to 1.27 mm to achieve optimal measurement accuracy.
• Use shielded triaxial cables to reduce electromagnetic interference during operation.
• Apply recommended torque values to ensure secure and stable installation.
• Keep wiring length below 305 metres to maintain signal quality and frequency response.

Packing List

• 1 × PROXPAC XL proximitor sensor unit
• 1 × Installation fittings set
• 1 × Accessory kit

FAQ

• Can this model operate without a probe?
  Yes, this configuration allows flexible integration with compatible external probes.
• What industries commonly use this sensor?
  Industries use this sensor for turbines, compressors, pumps, and rotating machinery monitoring.
• How do I ensure signal stability?
  Use proper shielding cables and maintain correct installation distance for stable performance.
• Is this model suitable for harsh environments?
  Yes, the IP66 housing and robust materials ensure reliable performance in demanding conditions.
