Bently Nevada 3500/45-01-01 | Position Monitor Module

Core Product Overview

• The Bently Nevada 3500/45-01-01 is a Position Monitor module.
• This module measures axial and radial position of rotating machinery.
• It accepts multiple transducer types with convenient internal terminations.

Key Technical Specifications

• Manufacturer & Model: Bently Nevada 3500/45-01-01
• I/O Module Type: 01 = Position I/O Module with Internal Terminations
• Agency Approval: 00 = No Special Agency Approvals
• Transducer Support: Proximitor, RPT, and DC LVDT inputs
• Operating Temperature: -30°C to +65°C (-22°F to +150°F)
• Humidity: 95% non-condensing operation
• Weight: 0.91 Kg total module weight

Functional & Environmental Features

• Transducer Compatibility: Supports Proximitor, RPT, DC LVDT sensors
• Internal Terminations: Built-in resistors simplify installation
• Temperature Range: Wide -30°C to +65°C operation
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Humidity Tolerance: 95% non-condensing capability
• Position Monitoring: Axial and radial position measurement

Physical & Installation Specifications

• Dimensions: 24.13 cm x 2.44 cm x 24.18 cm (HxWxD)
• Rack Space: Requires 1 full-height front slot
• Mounting: Standard 3500 series rack installation
• Connections: Internal terminations for transducer inputs
• Origin: Manufactured in the United States of America
• Documentation: Certificate of Origin (COO) available

Ordering & Configuration Details

• Base Model: 3500/45 Position Monitor
• First Option: 01 = Position I/O Module with Internal Terminations
• Second Option: 00 = No Agency Approval Option
• Complete Part Number: 3500/45-01-01
• Transducer Types: Proximitor, RPT, and DC LVDT compatible
• Condition: New original equipment from factory

Installation & Configuration

• Install the 3500/45-01-01 in a 3500 system rack
• Connect position transducers (Proximitor, RPT, or DC LVDT)
• Utilize internal terminations - no external resistors required
• Configure position monitoring parameters in 3500 software
• Set up alarm and danger limits for position measurements

Packaging & Delivery

• One Bently Nevada 3500/45-01-01 Position Monitor Module
• Original factory packaging with installation documentation
• Shipping via FedEx, UPS, or DHL express delivery
• Certificate of Origin available for international shipments

Frequently Asked Questions

What types of transducers does this module support?

The 3500/45-01-01 supports Proximitor, RPT, and DC LVDT position transducers.

What does "internal terminations" mean?

It has built-in termination resistors, eliminating need for external components.

What is the operating temperature range?

It operates from -30°C to +65°C in harsh industrial environments.

How much rack space does it require?

It requires one full-height front slot in the 3500 rack.

Where is this product manufactured?

It is manufactured in the United States of America.
