CI810B 3BSE020520R1 ABB AF100 Fieldbus Communication Interface

ABB 3BSE020520R1 CI810B AF100 Fieldbus Communication Interface

The ABB 3BSE020520R1 CI810B delivers comprehensive AF100 fieldbus connectivity with dual modem capability. This complete interface solution includes all necessary components for immediate industrial network deployment.

Product Identification & Specifications

• Product ID: 3BSE020520R1
• ABB Type Designation: CI810B
• Catalog Description: AF100 Fieldbus Communication Interface
• Exchange Number: EXC3BSE020520R1
• Software Version: Basic System 1.5

Physical Specifications

• Module Width: 158 mm
• Module Height: 250 mm
• Module Depth: 87 mm
• Net Weight: 0.5 kg
• Enclosure Rating: Industrial protection

Communication Features

• Fieldbus Protocol: AF100 standard
• Modem Configuration: 2 twisted pair modems
• Data Rate: 1.5 Mbps maximum
• Network Topology: Bus and tree support
• Node Capacity: 32 devices per segment

Included Components

• Power Supply Connector: 3BSC840098R1 (1 piece)
• Modulebus Terminator: TB807 3BSE008538R1
• Terminal Blocks: 3BSC840098R1 (2 pieces)
• AF100 Connector: 3BSC840105R1
• Pre-loaded Software: Version 1.5

Electrical Specifications

• Operating Voltage: 24 V DC nominal
• Power Consumption: 6 W typical
• Current Draw: 250 mA at 24V DC
• Isolation: 1500 V AC protection
• Noise Immunity: Industrial EMC standards

Environmental Specifications

• Operating Temperature: 0 to 55°C
• Storage Temperature: -25 to 70°C
• Relative Humidity: 5 to 95% non-condensing
• Vibration Resistance: 1.5 g, 10-150 Hz
• SCIP Registration: Estonia database

Network Performance

• Dual modem redundancy support
• Automatic baud rate detection
• Error detection and correction
• Real-time data exchange
• Network diagnostics capability

Installation Guidelines

• Install in compatible ABB control system
• Connect power supply connector properly
• Install Modulebus terminator for network end
• Configure twisted pair network topology
• Verify software version compatibility

Package Contents

• ABB 3BSE020520R1 CI810B interface unit
• Complete accessory kit included
• Installation and configuration manual
• Software documentation

Shipping & Delivery

• Fast FedEx, UPS, and DHL shipping
• ESD protective packaging
• Real-time tracking information
• International delivery available

Frequently Asked Questions

• How many modems are included? 2 twisted pair modems
• What software version is installed? Basic system version 1.5
• What components are included? Complete installation kit
• What is the module weight? 0.5 kilograms
• What are the dimensions? 158 x 250 x 87 mm
