CompactLogix DC Power Supply - 1769-PB2

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (17 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Allen-Bradley 1769-PB2 CompactLogix DC Power Supply

Key Features

  • Input Voltage: 19.2-31.2V DC (24V DC nominal)
  • Output Current: 2.0A @ 5V DC | 0.8A @ 24V DC
  • Module Capacity: Supports up to 16 I/O modules (8 per side)
  • Compact Design: DIN rail or panel mountable
  • Protection: 30A inrush current protection

Technical Specifications

Power Rating: 50VA @ 24V DC
Power Dissipation: 7.5W @ 60°C (140°F)
Fuse Type: Wickmann 19193-6.3A or Littelfuse 021706.3MXP
Dimensions: 118 x 70 x 87mm (4.65 x 2.76 x 3.43in)
Weight: 1.07 lbs (485g)
Certifications: c-UL-us, CE, C-Tick

Installation Notes

  • Requires 14 AWG (2.5mm²) copper wire (90°C rated)
  • 50mm clearance recommended for ventilation
  • Must be installed in protective enclosure
  • Proper grounding essential
  • Max wire insulation thickness: 1.2mm (3/64in)

Compatible Systems

  • CompactLogix 5370 controllers
  • 1769 I/O modules
  • MicroLogix 1500 systems
  • Studio 5000 programming environment

Package Information

  • 1769-PB2 power supply module
  • Installation documentation
  • UPC: 10662468992968
  • Shipping weight: 2 lbs (0.9kg)
  • Dimensions: 8 x 8 x 5 inches
