Emerson PR6423/010-010 Eddy Current Sensor | 8mm

The Emerson PR6423/010-010 eddy current sensor offers enhanced durability with armored cable protection for extreme industrial environments. This Emerson 8mm vibration probe delivers reliable performance in critical machinery monitoring applications.

Product Overview

• Brand & Model: Emerson PR6423/010-010
• Sensor Type: Eddy Current Vibration Probe
• Probe Diameter: 8 mm with armored cable
• Unit Weight: Approximately 100 grams
• Cable Protection: Armored construction for durability

Measurement Performance

• Linear Range: 2 mm (80 mils) full scale measurement
• Initial Gap: 0.5 mm (20 mils) recommended setting
• Sensitivity: 8 V/mm ±5% calibrated output
• Linearity: ±0.025 mm maximum deviation
• Accuracy Temperature: 0 to 45°C specified range
• Response Frequency: 0 to 10 kHz dynamic range

Mechanical Design

• Mounting Thread: M10x1 standard metric thread
• Housing Material: Stainless steel construction
• Tip Material: PEEK for mechanical strength
• Cable Type: Armored PTFE insulated cable
• Connector: Nickel-plated brass Lemo connector
• Cable Length: 5.0 meters standard length

Target Requirements

• Minimum Shaft Size: 25 mm diameter requirement
• Standard Material: 42CrMo4 (AISI 4140) steel
• Surface Condition: Ferromagnetic, smooth finish
• Alternative Materials: Available upon request
• Target Preparation: Clean, magnetic surface required

Environmental Specifications

• Protection Class: IP66 dust and water resistant
• Sensor Temperature: -35°C to +180°C operational
• Cable Temperature: -35°C to +150°C with connector
• Hazardous Certification: ATEX, IECEx, CSA approved
• Safety Standards: Intrinsic Safety (ia) and Non-sparking

Certifications & Standards

• EU Compliance: CE marked per EMC and ATEX directives
• International: IEC 60079 explosion protection series
• North American: CSA and UL hazardous location approval
• Temperature Classes: T3, T4, T6 classifications
• Quality System: Emerson quality management

Ordering Details

• Base Model: Emerson PR6423/010-010
• Thread Size: M10x1 standard mounting
• Cable Specification: 5.0 meter armored cable
• Connector Type: Lemo connector included
• Special Features: Armored cable protection

Frequently Asked Questions

• What brand manufactures this sensor? This is an Emerson product
• What is special about this model? Features armored cable for extra protection
• What temperature range does it support? Operates from -35°C to +180°C
• Is it suitable for explosive atmospheres? Yes, ATEX and IECEx certified
• What cable length is provided? 5.0 meter armored cable standard
• What connector type is used? Lemo connector for secure connection
• What is the sensor weight? Approximately 100 grams total weight
• What mounting thread is standard? M10x1 metric thread for installation
