FANUC A06B-6124-H209 | Industrial Servo Amplifier Module

Introducing the FANUC A06B-6124-H209 Servo Amplifier Module

The FANUC A06B-6124-H209 is a high-performance dual-axis servo amplifier module designed for demanding industrial automation systems. This robust unit from FANUC delivers precise power control for sophisticated motion applications. It ensures reliable operation in various manufacturing and processing environments with strict electrical requirements.

Core Technical Specifications

• Brand: FANUC
• Model: A06B-6124-H209
• Product Description: Servo Amplifier Module
• Number of Axis Amplifier: 2 independent axes
• Voltage Class: 400V system design
• Rated Output Current: 18.2 A (RMS) per axis
• Nominal Current Limit: 80 A (peak) capability
• Main Power Supply: Three-phase 400-480 VAC
• Control Power Supply: Single-phase 200-240 VAC
• Allowable Voltage Deviation: -15% to +10% range
• Power Frequency: 50/60 Hz, ±1 Hz accuracy
• Instantaneous Power Failure Guarantee: 3ms hold-up time
• Ambient Operational Temperature: 0 to 55°C
• Ambient Storage Temperature: -20 to 60°C
• Unit Weight: 8.62 kg (19.00 lbs)

Performance and Environmental Features

• The FANUC A06B-6124-H209 operates reliably up to 90% RH humidity
• Designed for condensation-free environments only
• Operational vibration tolerance below 0.5G for stable performance
• Instantaneous power failure protection with 3ms guarantee time
• Wide allowable voltage deviation range of -15% to +10%
• High peak current capability of 80A for demanding applications

Electrical and Power Specifications

• High-voltage 400V class design for industrial applications
• Requires three-phase main power (400-480VAC)
• Separate single-phase control power (200-240VAC)
• Precise frequency requirement: 50/60 Hz ±1 Hz
• Dual-axis configuration with independent current control
• Excellent current regulation and dynamic response

Installation and Application Details

• Designed for industrial control cabinet installation
• Suitable for high-power motion control applications
• Ideal for automation systems requiring dual-axis coordination
• Requires proper electrical isolation and safety measures
• Manageable 8.62 kg weight for installation handling
• Compatible with standard industrial power distribution

Packaging and Delivery Information

• Includes one FANUC A06B-6124-H209 servo amplifier module
• Heavy-duty industrial packaging ensures secure delivery
• Global shipping available via FedEx, UPS, or DHL carriers
• All necessary installation documentation included

Frequently Asked Questions (FAQ)

• How many axes does it control?
  The A06B-6124-H209 controls 2 independent axes.
• What is the main power requirement?
  Requires three-phase 400-480VAC main power supply.
• What is the rated output current?
  Provides 18.2 A RMS continuous current per axis.
• What is the peak current capability?
  Supports up to 80A peak current for brief periods.
• What is the operating temperature range?
  Functions from 0°C to 55°C ambient temperature.
• What power failure protection is offered?
  Guarantees 3ms operation during instantaneous failures.
