FC-SAO-0220M Honeywell Safe Analog Output Module

Honeywell FC-SAO-0220M Safe Analog Output Module

Technical Specifications

Type Numbers: FC-SAO-0220M

Approvals: CE, TUV, UL, CSA, FM

Space Requirements: 4 TE, 3 HE (= 4 HP, 3U)

Weight:0.3kg

Power Requirements

• 5 V DC: 30 mA
• 24 V DC: 65 mA + 30 mA for each active output

Output Specifications

• Number of Channels: 2
• Output Type: Active or passive, 0-20 / 4-20 mA
• D/A Converter: 12-bit
• Off Current: < 0.05 mA
• Maximum Load Capacitance: 100 nF

Loop Powering (Active)

• Maximum Loop Resistance: 600 Ω
• Maximum Output Voltage: 30 V DC

External Powering (Passive)

• Maximum Voltage: 40 V DC
• Minimum Voltage Drop: ≤ 7.5 V

WDG Input Current: 0.5 mA

Availability & Purchase Info

Stock: Honeywell FC-SAO-0220M modules are available for immediate dispatch.

Shipping: Orders ship within 5 business days via DHL or equivalent carriers.

Support: Technical guidance is available for integrating FC-SAO-0220M into safe analog control systems.

FAQ

Q: Is the FC-SAO-0220M module new?

A: Yes, all FC-SAO-0220M units are brand new and factory-sealed.

Q: How many analog output channels does it have?

A: It has two independent 0(4)-20 mA output channels for safe analog control.

Q: What is the power requirement?

A: 5 V DC: 30 mA, 24 V DC: 65 mA + 30 mA per active output.

Q: Does it include diagnostic features?

A: Yes, it performs regular output testing, de-energizing checks, and crosstalk monitoring.

Q: Can it be returned?

A: Yes, returns are accepted within 30 days if unused and in original packaging.
