Honeywell FC-MCAR-01 Mounting Carrier

Honeywell FC-MCAR-01 Mounting Carrier for IOTA-R24 Assembly

The FC-MCAR-01 provides a robust mounting solution for industrial control assemblies. This carrier securely holds one IOTA-R24 unit on any flat surface.

Product Overview

• Universal carrier for IOTA-R24 assembly installation
• Rigid metal profile with protective plastic cover plate
• Four precision mounting holes for secure fastening
• Easy installation on any flat surface configuration

Technical Specifications

• Model: FC-MCAR-01
• Operating Temperature: -40°C to +70°C
• Storage Temperature: -40°C to +85°C
• Voltage Rating: 24V DC (-15% to +30% range)
• Power Rail Current: 40A maximum capacity
• Humidity Range: 10-95% non-condensing
• Pollution Degree: 2 or better classification

Component Features

• Durable metal profile with plastic protective cover
• Comprehensive ground rail with 16 connection screws
• Two power rails with M5 holes for 24V and 0V connections
• Four mounting holes with 6.35mm diameter for secure fastening

Electrical Connections

• 24V power supply connections: 2 x M5 terminals
• Ground connections: 16 x M5 screw terminals
• High-current capacity supports demanding applications
• Reliable power distribution for connected assemblies

Physical Dimensions

• Size: 32 × 145.6 × 478 mm (H × W × D)
• Weight: 1.1 kg compact and lightweight design
• Space-efficient profile for optimized system layout

Certifications & Compliance

• CE and UL approved for industrial applications
• Complies with international safety standards
• Robust construction for long-term reliability
