Honeywell LG1093AA24 - Industrial Flame Sensor

LG1093AA24 UV Flame Sensor

The LG1093AA24 from Honeywell provides reliable flame detection for critical industrial applications. This UV flame sensor corresponds to GE part number 261A1812P012. It delivers precise flame monitoring with proven performance in gas turbine systems.

Product Specifications

• Manufacturer: Honeywell
• Model Number: LG1093AA24
• GE Part Number: 261A1812P012
• Product Type: UV Flame Sensor
• Sensor Technology: Geiger Mueller phototube
• Detection Method: UV radiation sensing
• Spectrum Range: 180-260 nanometer detection

Performance Specifications

• Operating Temperature: -40°C to +176°C range
• Flame Response Time: 0.1 seconds typical
• Flame Loss Response: 0.2 seconds maximum
• Viewing Window: High pressure rated construction
• Operating Distance: Up to 330 meters capability
• Sensor Life: 10,000 hours MTBF rating
• Shelf Life: Two years guaranteed performance

Electrical Specifications

• Amplifier Compatibility: EG1033 series modules
• Voltage Requirements: 28 VDC standard operation
• Voltage Range: 20-35 VDC flexible input
• AC Compatibility: 115 VAC system integration
• Output Options: Multiple configuration choices

Key Features

• Direct replacement for GE part 261A1812P012
• Solar blind UV detection technology
• Black body radiation tolerance
• Fast response flame detection
• Proven gas turbine application experience
• High reliability and long service life

Certifications & Approvals

• ATEX Certified for hazardous areas
• Factory Mutual approval
• CE Mark compliant
• Class I, Division 1 & 2 certification
• International safety standard compliance

Application Areas

• General Electric gas turbine systems
• Power generation flame monitoring
• Industrial combustion safety
• Compressor station protection
• Process heating equipment

Compatibility Information

• Direct replacement for GE 261A1812P012
• Compatible with EG1033 amplifier series
• Suitable for most GE turbine applications
• Verify specific model compatibility for DLE turbines

Frequently Asked Questions

What is the GE equivalent part number?

• This sensor replaces GE part 261A1812P012.
• It provides identical performance specifications.
• Direct replacement without system modifications.

What is the typical response time?

• Flame detection occurs within 0.1 seconds typically.
• Flame loss detection takes maximum 0.2 seconds.
• Fast response ensures immediate safety actions.

Is this sensor suitable for GE turbines?

• Yes, it is designed for GE turbine applications.
• However, verify compatibility for DLE Low-NOx models.
• Some specific applications may require different variants.

What certifications does it carry?

• The sensor has ATEX hazardous area certification.
• It carries Factory Mutual approval.
• CE marking ensures European market compliance.

What is the operating temperature range?

• It operates from -40°C to +176°C.
• This wide range suits extreme environments.
• Reliable performance in both hot and cold conditions.

What amplifier is required?

• Compatible with EG1033 amplifier series.
• Multiple output configurations available.
• Choose amplifier model based on control system needs.
