IC693ALG223 | Analog Current Input Module GE Fanuc

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (30 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

IC693ALG223 | GE Fanuc Analog Current Input Module

The IC693ALG223 module is a sophisticated 16-channel analog current input solution.

Features at a Glance:

📊 Input Channels: Up to 16, selectable per channel.

🌐 Input Ranges: 4 to 20 mA, 0 to 20 mA, 4 to 20 mA Enhanced

🔧 Calibration:

  • • 4 µA/count (4 to 20 mA range)
  • • 5 µA/count (0 to 20 mA and 4 to 20 mA Enhanced ranges)



Performance Specifications:

⏰ Update Rate: 13 msec for all channels.

🔍 Resolution:

  • • 4 µA (4-20 mA range)
  • • 5 µA (0-20 mA and 4-20 mA Enhanced ranges)



🌡️ Absolute Accuracy: ± 0.25% of full scale @ 25°C (77°F); ± 0.5% over the operating temperature range.

🔌 Input Impedance: 250 ohms; ⚡ Isolation: 1500 volts between field and logic sides.

Additional Information:

💡 Cross-Channel Rejection: > 80 dB from DC to 1 kHz.

🔒 Low Pass Filter Response: 19 Hz for optimal signal integrity.

🔋 Power Requirements:

  • • 120 mA from the +5V bus
  • • 65 mA from 24 VDC user supply



⚖️ Weight: 0.5 kg.

Why Choose IC693ALG223?

This module is designed for industrial applications where data accuracy and reliability are paramount.

  • Quick Quotes: Receive pricing and availability fast from our dedicated customer service team.
  • Delivery: Expedited, freight, and international shipping available worldwide.
  • Warranty: NexAuto offers a 12-month warranty on all parts purchased from us, in addition to any manufacturer coverage.
  • Returns: 30-day return policy for defective or mismatched parts, ensuring peace of mind.
  • Payment: Flexible options including major credit cards, PayPal, and bank transfers.
  • Custom Calibration: Provide your specifications, and we’ll handle the rest with precision.
