Input Module Allen-Bradley 1734-IB8/C

Allen-Bradley 1734-IB8/C POINT I/O Digital Input Module

The Allen-Bradley 1734-IB8/C is an 8-point DC sinking input module designed for POINT I/O systems. It provides reliable signal acquisition from sensors and switches in industrial environments.

Technical Specifications

• Manufacturer: Allen-Bradley
• Model: 1734-IB8/C
• Series: POINT I/O
• Input Type: 8 DC sinking channels
• Input Voltage Range: 10-31.2V DC
• Input Current: 5 mA maximum per point
• Off-State Voltage: 0-5V DC
• On-State Voltage: 10-31.2V DC
• Input Impedance: 2.4 kΩ
• Response Time: 2 ms maximum
• Isolation Voltage: 50V

Environmental Ratings

• Operating Temperature: -20°C to 55°C
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 5-95% non-condensing
• Power Dissipation: 1.6 W maximum
• Thermal Dissipation: 5.5 BTU/hr

Installation and Compatibility

This module mounts on standard DIN rail. It connects directly to POINT I/O adapters. Works with Allen-Bradley POINT I/O system components.

Industrial Applications

• Machine safety interlock monitoring
• Limit switch and proximity sensor reading
• Push button and selector switch status
• Process control system input signals
• Material handling equipment sensing

Package Contents

• One 1734-IB8/C input module
• Installation documentation
• Product specification sheet

Warranty and Support

12-month product warranty. Available for immediate shipping via FedEx, UPS, DHL. Technical support provided.
