Invensys 3636T Relay Output Module Overview

The Invensys 3636T Relay Output Module provides reliable control for non-critical applications. This non-triplicated module works with devices like annunciator panels that require traditional relay switching. It processes signals from three independent processor channels and uses majority voting to operate 32 individual relays.

Key Features and Diagnostics

• Continuous diagnostic monitoring checks module health in real-time
• Each output includes load-independent loopback verification
• Instant fault indication with chassis alarm activation
• Hot-spare module support for maximum system availability
• Easy integration via External Termination Panel (ETP)
• Silver blue enclosure for quick visual identification

Technical Specifications

• Brand: Invensys
• Model: 3636T
• Type: Non-Triplicated
• Points: 32 isolated channels
• Voltage: 155V AC/DC maximum
• Current: 2A per point maximum
• Switching Capacity: 2000 VA, 150W resistive
• Isolation: 2500 VDC point-to-point
• Fusing: 2.5A fast-acting per output
• Contacts: Normally Open configuration
• Diagnostics: Per-point status and module health indicators

Installation Requirements

• External Termination Panel (ETP) required for installation
• Standard cable interface to Tricon backplane
• Professional installation recommended
• Adequate ventilation and spacing required

Shipping Information

• Worldwide shipping via FedEx, UPS, and DHL
• Secure packaging with protective materials
• Tracking information provided for all shipments
• Express delivery options available

Frequently Asked Questions

• What applications suit the 3636T module?
  Perfect for annunciator panels, alarm systems, and non-critical control points.
• How does the voting system work?
  Three processor signals are compared, and the majority decision controls the relays.
• What happens during a fault?
  The fault LED activates and triggers the chassis alarm for immediate attention.
• Are the relays individually protected?
  Yes, each output has its own 2.5A fast-acting fuse for complete protection.
