MTL3013 Dual-Channel Hazardous Area Interface: Reliable Dual Control

The MTL3013 from MTL Instruments provides two independent control channels in one compact unit. This interface connects NAMUR sensors to control systems in hazardous locations. It offers flexible configuration and clear status monitoring for industrial applications.

Core Features and Operation

• The MTL3013 provides two completely independent control channels in one space-saving unit.
• It accepts NAMUR-compliant sensor inputs with 7-8.5V DC power supply requirements.
• Each channel features configurable phase reversal for installation flexibility.
• Dual LED status indicators give clear visual feedback for both channels separately.

Detailed Technical Specifications

• Brand: MTL Instruments
• Model: MTL3013
• Input Thresholds: Closes at >2.1mA and opens at <1.2mA current levels
• Relay Rating: Handles 250V at 5A for robust switching capability
• Response Time: Fast 10ms operation for immediate control actions
• Power Supply: Operates from 20-35V DC input voltage range
• Power Consumption: Draws only 55mA at typical 24V operation
• Unit Weight: Compact design weighing just 170g for easy installation

Safety Certifications and Compliance

• The interface carries Zone 0, IIC, T6 certification for hazardous environments.
• It meets Division 1, Group A compliance standards for North American markets.
• FM Entity Parameters ensure intrinsic safety with Voc=10.5V and Isc=14mA.
• These safety ratings make it suitable for the most demanding hazardous locations.

Channel Logic and Operation

• Sensor Current >2.1mA (resistance <2kΩ) triggers relay closed position.
• Sensor Current <1.2mA (resistance >10kΩ) triggers relay open position.
• Built-in 200μA hysteresis (approximately 650Ω) prevents contact chatter.
• This reliable switching logic ensures stable operation in noisy environments.

Common Industrial Applications

• Dual safety interlock systems for critical process protection.
• Hazardous area machine control in manufacturing facilities.
• Process automation interfaces between field and control room.
• Emergency stop circuits for personnel and equipment safety.

Package Contents and Accessories

• One complete MTL3013 dual-channel controller unit.
• Detailed installation documentation with wiring diagrams.
• One 80mA replaceable fuse for circuit protection.
• Full set of mounting hardware for panel installation.
