Allen-Bradley 2711P-K6M20A8 PanelView Plus 6 600 Operator Interface Terminal

The 2711P-K6M20A8 from Allen-Bradley represents the enhanced performance generation of PanelView Plus 6 terminals. This advanced operator interface combines substantial memory capacity with reliable monochrome display technology for demanding industrial applications.

Display & Visual Features

• High-Performance Display: 5.7 inch monochrome grayscale TFT LCD
• Generous Viewing Area: 115 x 86 mm active display space
• Crisp Resolution: 320 x 240 pixel clarity with sharp detail
• Advanced Grayscale: 16-level grayscale for enhanced visual presentation
• Long-Life Backlight: White LED with 25,000 hour minimum lifespan

Memory & Processing Power

• Enhanced System Memory: 256 MB RAM for superior performance
• Substantial Storage: 512 MB non-volatile memory capacity
• User Application Space: Approximately 79 MB available for user programs
• Advanced Processing: Enhanced memory supports complex applications
• Future-Ready Capacity: Ample storage for sophisticated HMI projects

Power & Electrical Specifications

• Universal AC Input: 100-240 VAC wide range compatibility
• Global Frequency: 50-60 Hz operation for worldwide use
• Modern Power Design: Compatible with international power standards
• Installation Flexibility: Suitable for various industrial power systems
• Reliable Operation: Stable performance across voltage variations

Keypad & Input Features

• Durable Keypad Design: 1 million press lifespan for long service
• Programmable Function Keys: F1-F10 keys for custom application control
• Complete Input Set: Dedicated numeric and navigation keys
• Operator-Friendly Layout: Intuitive key arrangement for easy use
• Industrial Durability: Built to withstand continuous daily operation

Communication & Connectivity

• Network Connectivity: 10/100Base-T Ethernet with auto-sensing
• Serial Communication: RS-232 port for legacy device support
• Peripheral Support: USB port for external device connection
• Modern Networking: RJ45 connector with MDI/MDI-X auto-negotiation
• Comprehensive Integration: Multiple interface options for system flexibility

Environmental Specifications

• Operating Temperature: 0 to 55 degrees Celsius reliable operation
• Enclosure Protection: NEMA 12, 13, 4X and IP54, IP65 ratings
• Indoor Application: Designed for controlled industrial environments
• Robust Construction: Built to withstand typical industrial conditions
• Quality Materials: Industrial-grade components throughout

Physical Characteristics

• Substantial Build: Approximately 6 pounds total weight
• Shipping Dimensions: 14 x 11 x 8 inches packaged size
• Industrial Design: Robust construction for panel mounting
• Secure Packaging: Protective shipping dimensions ensure safe delivery
• Professional Installation: Standard industrial mounting provisions

Installation Advantages

• Universal AC power input simplifies global deployment
• Enhanced memory capacity supports complex applications
• Multiple communication ports ensure broad compatibility
• Durable keypad withstands high-use environments
• Standard enclosure ratings for industrial installation

Application Solutions

• Complex HMI applications requiring substantial memory
• Industrial processes needing reliable operator interface
• Manufacturing systems with extensive data display requirements
• Global installations requiring universal power compatibility
• Applications demanding durable, long-life keypad operation

Technical Support Information

• Q: What memory capacity does this terminal offer?
• A: Enhanced 256 MB RAM with 512 MB storage for complex applications
• Q: What power supply requirements are needed?
• A: Universal 100-240 VAC input for global installation
• Q: How durable is the keypad?
• A: Rated for 1 million presses with programmable function keys
• Q: What is the backlight lifespan?
• A: White LED backlight with 25,000 hour minimum service life
