Emerson A6500-ATG System Relay Card

The Emerson A6500-ATG is an advanced system relay card designed for high-performance machinery protection systems. This robust module offers enhanced reliability and flexibility for critical industrial applications.

Technical Specifications

• Brand: Emerson
• Model: A6500-ATG
• Module Size: 3U, 4-slot configuration
• Rack Compatibility: A6500-SR series
• Compliance Standards: API 670, IEC 61508
• Hot-swappable: Yes, with live insertion capability
• Digital Inputs: 72 channels
• Analog Inputs: 8 channels, 16-bit resolution
• Logic Processors: 24 configurable networks
• Relay Outputs: 24 SPDT relays
• Power Supply: 24 VDC ±10%, dual redundant
• Power Consumption: Max 8W typical operation
• Processing Speed: 1 ms scan time
• Memory Capacity: 16 MB non-volatile memory

Environmental Specifications

• Protection Rating: IP 52 front panel
• Operating Temperature: -25°C to +75°C
• Storage Temperature: -40°C to +85°C
• Relative Humidity: 5-95% non-condensing
• Vibration Resistance: 2.5g @ 10-150 Hz
• Shock Resistance: 15g, 11ms duration
• EMC Immunity: EN 61326-1, Level 3
• EMC Emissions: EN 61326-1, Class A

Output Specifications

• Relay Type: SPDT, gold-plated contacts
• Contact Rating: 5A @ 30 VDC, 2A @ 250 VAC
• Max Switching Voltage: 250 VAC, 30 VDC
• Max Switching Current: 5A resistive
• Mechanical Life: 10 million operations
• Electrical Life: 100,000 operations @ rated load
• Operate Time: 5 ms maximum
• Release Time: 3 ms maximum

Physical Dimensions

• Height: 133.4 mm (3U)
• Width: 84.8 mm (4TE)
• Depth: 160 mm
• Weight: 320 g
• Mounting: DIN rail or panel mount

Package Contents

• A6500-ATG Relay Card
• DIN rail mounting kit
• Configuration cable
• Installation manual
• Safety certification documents
