Probe Housing 32000-28-05-05-060-00-02 Bently Nevada

Bently Nevada 32000-28-05-05-060-00-02 Probe Housing Assembly

• Manufacturer & Model: Bently Nevada 32000-28-05-05-060-00-02 probe housing assembly for 31000 and 32000 series proximity probes.
• Product Type: Compact probe housing for tight machinery mounting locations.
• Compatible Series: 31000 and 32000 series 8mm proximity probes.
• Made in: U.S.A.
• Housing Material: 316 stainless steel with electropolished finish.
• Mounting Thread: 1/2-14 NPT standard pipe thread.
• Probe Bore Diameter: 8 mm (0.315 in) for standard 8mm probes.
• Overall Length: 60 mm (2.36 in) compact design.

Dimensional Specifications

• Housing Outer Diameter: 28 mm (1.10 in) for tight spaces.
• Hex Flats Size: 28 mm wrench flats for installation.
• Thread Length: 5 mm (0.20 in) short thread section.
• Probe Insertion Depth: Adjustable from 0 to 25 mm.
• Lock Nut Included: Yes, low-profile lock nut.
• Housing Weight: Approximately 0.18 kg (0.40 lb) per assembly.

Ordering Code Breakdown

• 32000-28-05-05-060-00-02: Complete housing assembly part number.
• 32000: Series designation for probe housing family.
• 28: Outer diameter of housing in mm (compact size).
• 05: Thread length in mm (short thread).
• 05: Material option (electropolished 316 stainless steel).
• 060: Overall housing length in mm (short).
• 00: No special coating option.
• 02: Seal option (Viton O-ring included).

Installation Specifications

• Mounting Type: Through-hole with low-profile lock nut.
• Torque Requirement: 20 Nm (15 lb-ft) maximum for installation.
• Seal Type: Viton O-ring in groove.
• Pressure Rating: 3500 psi (24.1 MPa) with proper seal.
• Temperature Range: -50°C to 180°C (-58°F to 356°F).
• Tool Required: 28 mm open-end wrench or adjustable wrench.

Compatibility Information

• Compatible Probes: 31000 and 32000 series 8mm proximity probes.
• Compatible Extension Cables: 31000 and 32000 series cables.
• Machine Interface: 1/2-14 NPT threaded port on casing.
• Gap Setting Range: 0.8 mm to 2.0 mm nominal probe gap.
• Minimum Casing Wall: Works with walls as thin as 3 mm.

Environmental and Durability

• Corrosion Protection: Electropolished 316 stainless steel surface.
• Vibration Resistance: Tested to 25g at 10 Hz to 2 kHz.
• Shock Resistance: 75g peak, 11 ms half-sine pulse.
• IP Rating: IP67 when properly sealed with O-ring.
• Chemical Resistance: Resistant to most industrial fluids and solvents.
• Low Profile Design: Extends only 60mm from mounting surface.

Package Contents and Shipping Information

• Included Components: Housing body, low-profile lock nut, Viton O-ring.
• Documentation: Installation sheet with gap setting guide.
• Shipping Weight: Approximately 0.22 kg (0.48 lb) per assembly.
• Packaging: Anti-static bag inside foam-lined box.
• Express Shipping Options: FedEx, UPS, or DHL worldwide.

Frequently Asked Questions

• Q: What makes the 32000-28-05-05-060-00-02 different from standard housings?
  A: This is a compact housing with 28mm OD and 60mm total length. It fits tight machinery spaces where standard 30mm x 95mm housings cannot go.
• Q: What thread size does this housing use?
  A: The 32000-28-05-05-060-00-02 uses 1/2-14 NPT thread. This smaller thread works for machines with limited port space.
• Q: What is the pressure rating for this compact housing?
  A: This housing handles up to 3500 psi (24.1 MPa). The lower rating reflects the smaller thread size compared to 3/4-14 NPT housings.
• Q: What probes fit the 32000-28-05-05-060-00-02 housing?
  A: The housing accepts 31000 and 32000 series 8mm proximity probes. The -00-02 suffix specifies standard 8mm probe compatibility with Viton seal.
• Q: How do I install this compact housing?
  A: Thread into a 1/2-14 NPT port using a 28mm wrench. Maximum torque is 20 Nm (15 lb-ft). The short 5mm thread requires careful alignment.
