Schneider Electric 140CPS52400C | 8A Power Supply Module

Schneider Electric Modicon Quantum Power Supply Module

The Schneider Electric 140CPS52400C is a redundant power supply module for the Modicon Quantum automation platform. This module provides stable DC power for industrial control systems. It features a wide input voltage range and built-in protection mechanisms.

Electrical Specifications

• Product Model: Schneider Electric 140CPS52400C
• Input Voltage: 100-150 V DC (125 V DC nominal)
• Output Voltage: 5.1 V DC regulated output
• Output Current: 8 A maximum redundant output capacity

Power & Protection Features

• Inrush Current: 28 A maximum at 125 V DC input
• Hold-up Time: ≤1 millisecond during power interruption
• Overvoltage Protection: Internal protection circuitry
• Overload Protection: Internal current limiting protection

System & Safety Features

• Power Dissipation: 6 + (1.5 × Iout) watts calculation formula
• Fuse Protection: 2 A slow-blow fuse for input protection
• Status Indicator: Green LED for "PWR OK" status indication
• Redundant Design: Supports redundant power supply configuration

Environmental Specifications

• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Humidity Rating: 95% relative humidity non-condensing
• Operating Altitude: Up to 5000 meters (16404 feet)

Certifications & Compliance

• Safety Certifications: cUL, FM Class 1 Division 2, UL 508, CSA
• ESD Protection: 4kV contact, 8kV air discharge (IEC 801-2)
• EMC Immunity: 10V/m at 80-2000MHz (IEC 801-3)
• Protective Coating: Conformal coating Humiseal 1A33

Physical Specifications

• Module Format: Standard Quantum series module size
• Net Weight: 0.65 kg (1.43 lb) module weight
• Package Dimensions: 4.5cm × 16.5cm × 31.5cm
• Package Weight: 0.915 kg (32.3 oz) total shipping weight

Installation Guidelines

• Install in Modicon Quantum backplane with proper alignment
• Ensure input voltage stays within 100-150 V DC operating range
• Use recommended 2 A slow-blow fuse for circuit protection
• Allow adequate ventilation for heat dissipation requirements

Shipping Information

• Package includes Schneider Electric 140CPS52400C power module
• Country of origin: China (CN) manufacturing location
• International shipping via major carriers available
• Standard package with protective materials included

FAQ

• What is the input voltage range? 100-150 V DC operation
• What output does it provide? 5.1 V DC at 8 A maximum
• What is the hold-up time? ≤1 millisecond during interruption
• Is it redundant capable? Yes, supports redundant configuration
• What certifications does it have? cUL, FM Class 1 Div 2, UL 508
