Siemens Compact Controller 6ES7212-1BE40-0XB0

Siemens SIMATIC S7-1200 CPU 1212C Versatile Compact PLC

The Siemens 6ES7212-1BE40-0XB0 offers flexible power options in a compact automation controller. This efficient CPU 1212C model supports wide AC voltage ranges alongside comprehensive I/O capabilities. It provides reliable performance for various industrial control applications with easy installation.

Core Technical Specifications

• Brand: Siemens
• Model: 6ES7212-1BE40-0XB0 (CPU 1212C AC/DC/Relay)
• Power Supply: 85-264 V AC, 47-63 Hz universal input
• Integrated I/O: 8 Digital Inputs (24V DC), 6 Relay Outputs (2A), 2 Analog Inputs (0-10V)
• Program Memory: 75 KB work memory with 2 MB load memory
• Communication: Built-in PROFINET interface with 100 Mbit/s speed
• Operating Temperature: -20 °C to 60 °C horizontal installation

Comprehensive Input and Output Configuration

• The eight digital inputs handle 24V DC signals with configurable filtering
• Six inputs support high-speed counting up to 100 kHz for precise measurement
• Six relay outputs control resistive loads up to 2A with 10 ms switching
• Two analog inputs process 0-10V signals with 10-bit resolution accuracy
• Fast 625 µs conversion time per analog channel ensures quick response

Advanced Communication Features

• Integrated PROFINET interface supports both controller and device roles
• Multiple industrial protocols including TCP/IP, ISO-on-TCP, and UDP
• OPC UA server functionality enables secure data communication
• Integrated web server allows remote monitoring and configuration
• Supports expansion with 2 signal modules and 3 communication modules

Environmental Durability and Compliance

• Wide operating temperature range from -20°C to 60°C for tough conditions
• High immunity to electromagnetic interference and power disturbances
• Withstands vibrations up to 2g and mechanical shocks for industrial use
• IP20 protection ensures safety against contact with small objects
• Carries CE, UL, cULus, FM, and marine approvals for global deployment

Installation and Setup Guidelines

• Mount on standard DIN rails in control cabinets or industrial panels
• Use shielded cables for analog signals, maximum 100 meters length
• Digital inputs support unshielded cables up to 300 meters distance
• Ensure proper spacing for ventilation at higher ambient temperatures
• Follow electrical standards and local safety codes during installation

Packaging and Shipping Information

• Package Dimensions: 10.70 x 10.30 x 8.50 cm (L x W x H)
• Net Weight: 0.374 kg
• Shipping Weight: Approximately 0.425 kg
• Contents: One Siemens CPU 1212C unit (6ES7212-1BE40-0XB0)
• We ship internationally using FedEx, UPS, and DHL express services

Frequently Asked Questions

• What software is needed for programming? STEP 7 (TIA Portal) V16 or higher
• How many expansion modules can be added? Up to 2 signal modules and 3 communication modules
• What is the relay contact operational life? 100,000 cycles at rated load conditions
• Does it support high-speed counting? Yes, six inputs support counting up to 100 kHz
• What power voltages does it accept? Universal 85-264 V AC, 47-63 Hz input range

For detailed technical specifications and purchasing assistance, contact our experts. Reach us via WhatsApp or send an email for prompt support.
