Triconex 3564 Digital Input Module | 24VDC 16-Channel

Triconex 3564 Digital Input Module, 24 VDC

The 3564 provides reliable 24VDC digital input acquisition for industrial control systems. This module delivers precise signal conditioning with comprehensive diagnostic coverage for safety-critical applications.

Key Features

• 16-channel isolated input
• 24VDC industrial standard input
• Advanced contact bounce filtering
• Real-time health monitoring
• Hot-swappable operation
• TMR architecture compatible

Technical Specifications

Input Characteristics:

• Input Channels: 16 points isolated
• Input Voltage: 24VDC nominal
• On-state Voltage: 15-30VDC
• Off-state Voltage: 0-5VDC
• Input Current: 6mA typical @ 24VDC
• Response Time: 3ms maximum
• Contact Bounce Filter: Programmable 0-25ms

Isolation & Protection:

• Channel-to-Channel: 1000V RMS
• Channel-to-Backplane: 1500V RMS
• Surge Protection: 1kV line-to-line
• ESD Protection: 6kV contact discharge
• Reverse Polarity Protection: Yes

Power Requirements:

• Backplane Power: 5VDC ±5%
• Module Consumption: 3.5W typical
• Inrush Current: 10A maximum

Environmental Specifications:

• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 5-95% non-condensing
• Vibration: 2g @ 10-500Hz operational
• Shock: 15g for 11ms
• MTBF: >300,000 hours

FAQ

What input voltage does the 3564 support?
24VDC nominal with 15-30VDC operating range.

How many input channels are available?
16 isolated input channels with individual status monitoring.

Is the module hot-swappable?
Yes, supports live insertion and removal during operation.

What is the response time?
3ms maximum with programmable contact bounce filtering.

What protection features are included?
Surge protection, ESD protection, and reverse polarity protection.

What is the operating temperature range?
0°C to 60°C with full performance.
