Triconex 3625A Digital Output Module | 32-Channel

Triconex 3625A Digital Output Module | 32-Channel 24VDC Brand New

The Triconex 3625A provides advanced 32-channel digital output control for industrial safety systems. This brand new module operates at 24VDC nominal voltage with comprehensive diagnostics. The Triconex 3625A features point supervision and short/open circuit detection capabilities. Engineers select this module for applications requiring high-density output with advanced monitoring features.

Technical Specifications

• Brand: Triconex
• Model: 3625A
• Product Type: Digital Output Module
• Condition: Brand New Original Factory Seal
• Color Code: Dark Blue
• Output Signals: 32 channels, commoned
• Nominal Voltage: 24 VDC
• Voltage Range: 16-32 VDC recommended
• Maximum Voltage: 36 VDC absolute maximum
• Logic Power: < 13 watts
• Current Rating: 1.70±10% amps per point
• Surge Current: 5 amps for 7 milliseconds
• Total Module Current: 10 amps maximum
• Minimum Load: 10 mA required
• Output Leakage: 2.0mA@24VDC, 2.5mA@32VDC
• Isolation: 1,500 VDC minimum system-to-field

Common Questions

• How many output points does the module have? The module provides 32 commoned digital output channels.
• What protection features are included? Output switches are self-protected against over-voltage and over-current.
• What status indicators are available? Per-point On/Off state, Module Status, and Field Alarm indicators.
• Can each point be individually supervised? Yes, point supervision can be programmed per individual output point.
• What detection capabilities are provided? Programmable short circuit and open circuit detection per supervised point.
